Full Automatic Onion Peeling Machine/0086 15864704018

Specifications

Full automatic onion peeling machine

1. Technical Parameters:
Efficiency: 6000pcs/hr  (1ton/hr)

Material: stainless steel

Power: 6kw

Voltage: 380v

Size: 3.7x1.5x2.2(m)

Weight:1.5ton

(customer need to equip an air compressor  6kg/cm)

2. Feature:

This full automatic onion peeling  machine is used to peel the first and the second layer skin, and also cut the top & bottom end of onion  at the same time.

3. the main process flow:

Raw material (onion) into the feeding hopper manually — automatic chain feeder send onion to skin scriber box — gash onion send to Onion systemizing part to adjust the direction, then onion placed by machine to the synchro-belt to ensure the evenly distance and proper position — the automatic fixture clamp the onion and send to the blades to delete root hair, then release to the peeling device — onion will be peeled by the spiral working and high-pressure air blow nozzle , then will be sent to discharge hole. Whole onion peeling processing procedures are finished.
