30tpd, 50tpd, 100tpd wheat flour mill brief introduction
1.The flour milling plant fits for the production of tailored flour and all-purpose flour.
2.The flour mill is with advanced technical process and flexiable adjustment. It can produce grade flour and special flour. The finished flour is usually used to produce bread, biscuit, spaghetti, instant noodle, etc
3.The machine adopts full steel structure, featuring handsome appearance, easy installation and small occupation. The wheat flour mill can be designed and installed together with the steel structure support. The main support structure is made of three levels: the roller mills are located on the ground floor; the sifters are installed on the first floor and the cyclones and pneumatic pipes are on the second floor.
Wheat flour mill complete line
Characteristics of our wheat flour mill
1. it has stable performance and high flour yield, The flour screening adopts efficient double bin plansifter; the screen adopts stainless steel wire mesh, difficult for blocking.
2.The whole machine adopts pneumatic and negative pressure transmission, not only preventing smell from leakage, but also reducing workshop dust and drying the flour in this process.
3.The air outlet of the blower can be equipped with pulse deduster, making your working environment cleaner.
4.The plpe all adopts Φ precast pipe. In every floor of pipe all set sight glass and inspection door; In each lifting pipe set sight glass far from the platform 150mm.
| Type | Power (kw) | Line Dimensions(m) | Brief process |
| 6FYDT-30 | 87.2 | 16*7*7 | Cleaning part: 2 siftings--2 scourings--1 destoning ---1 washing--2 magnetic separations;
Milling part: 3 hulling and 3 wheat core millings, separating wheat skin from wheat core to grind them partly.
|
| 6FYDT-40 | 128.6 | 20*7*7.5 | Cleaning part: three sieves, two beating, two removing stone, One washing and three magnetic selecting
Milling part: eight milling, two six-bin square sifter, one purifier and two bran finishers making up "4B,7M, 1S, 2T" process .
|
| 6FYDT-50 | 135.5 | 28*7*7.5 | Cleaning part: One screen, two scour, two destoner, one damper, and one magnetic separator.
Milling part: Four sets of double roller mill, three sets of Double-section high efficiency square sifter consist of the milling technology of four break, three reduction, one scratch ,one bran brusher |
| 6FYDT-100 | 150 | 35*7*15.7 | Cleaning part: 4 break-5 reduction-1 scratch-1tail-2 purifying-1 inspection-2 bran brushing
Milling part: 3 sifting-2 scouring-2 destoning-3 magnetic separating-1 washing-2 dampening |
1.Triple cleaning sieve: Through the beat function of the wheat scourer, brusher to remove dust sand small seed, bacterial count and insect seed.
2.Damper: Dampening the wheat bran before mill to ensure the bran's integrity during the milling processing, avoid the bran going into the flour to keep flour quality.
3.Wheat scourer: clean the surface of the wheat, ensure that the play ash content of wheat finished points can reach to the standard.
4.Rotary sieve classifier: through value drive shaft makes the sifter planar rotating to separating the impurities from the grains.
5.Milling machine: Mill the wheat to break the integrity by the roller moving
6.Double-bin plansifter: To separate the flour and bran, also separate large size and small size to enssure flour quality.
7.Bran brusher: separate the fine particle from the surface of wheat bran. Thus reducing the rate of the bran, enhance the rate of the powder.
8.Fan: offer wind force, wind pressure
1. Raw wheat storage(silo or warehouse)
2. Cleaning system(sifter, destoner, magnetic separation, scourer)
3. Milling system(roller mill, plansifter, purifier, impact detacher)
4. Flour packing and stacking
We offer the technology flow chart
Output: wheat flour ( finess is adjustable)
Packing and shipping
Welcome friends from all over the world
How to choose a flour mill?
Two of the features that affect prices are the material of the flour mill, the noise level and their adjustability. Generally, our turn-key project of flour mill is made of stainless steel, operate with low noise level, have lower heat production, generate less dust in the air.
Our work range:
1.Series of corn product line ( flour ), ( Grits, flour ) ,( flour,grits,germ ) , (flour,germ)
2.Wheat flour milling production line ( fine wheat flour ) ( whole wheat flour )
3.Buckwheat processing line
4.Corn gluten flour production line
