Muti-functional grain cleaing machine
To clean out the impurities which is light, heavy, with different sizes and weight in the raw corn, to achieve an effect of high efficiency and low investment, our engineer designed this new condition combined screen with both the function of bolting and destoning. It is combined the function of vibrating screen and detone machine of which the structure integrate both of them into one to reduce the equipment dimension and investment of labor and money. Moreover this set of screen reduces appliacation of winnowing equipment, reducing the technical problem and it is easy to install and operate.
Feature:
1.Dedicated grain cleaning equipment, integrating function of vibrating sieve and destoner, achieving the effect of destoning and impurities removal by only using the combined screen;
2. Reasonable, scientific design, decreasing the customer’s investment on the equipment;
3.Compact structure, having small occupied area;
4. Stable operation, small power consumption;
5. Easy to install and maintain, reducing the user’s post expense.
Techincal parameter
| Model | Width of sieve (mm) | Capacity (t/h) | Air suction volumem (m³/h) | Air pressure (Pa) | Ampllitude (mm) | Sifter dip angle (°) |
| TQLS85 | 850 | 1-1.5 | 4000 | ≤980 | 4--5 | 5--9 |
| TQLS100 | 1000 | 1.5-2 | 5000 | ≤980 | 4--5 | 5--9 |
| TQLS120 | 1200 | 2--3 | 6000 | ≤980 | 4--5 | 5--9 |
| TQLS160 | 1600 | 3--4 | 8000 | ≤980 | 4--5 | 5--9 |
| Model | Revolving speed (r/min) | Matching power (kw) | Overall dimension (mm) | Blower model (mm) | Weight (kg) |
| TQLS85 | 980 | 0.5 | 1170*110*2170 | 4-72-No.4.5 | 592 |
| TQLS100 | 980 | 0.5 | 1220*1270*2170 | 4-72-12No.5 | 642 |
| TQLS120 | 980 | 0.5 | 1496*1445*2170 | 4-72-12No.5 | 713 |
| TQLS160 |
1) Pre-sale service: Freely provide project designing, process designing, select suitable equipment for customer.
2) Order execution service: Provide equipment layout draw, foundation draw and detail equipment manuals. Timely report youthe manufacturing schedule and related photos for keep monitoring.
3) After-sales service: Dispatch engineer to the site to guide installation, debugging and training operators. Installation and operation workers are offered if you need.
Chuanyue Machinery Co.,Ltd is a professional manufacturer of all types of flour milling machine for wheat/maize/corn and rice, integrating development and production together.
Our products are exported to Belgium, Egypt, Algeria, Zambia, Kenya, Ethiopia, Uganda, Tanzania, Vietnam, and other countries.
