200tpd maize grinding mill prices for maize grits, flour, germ
Brief craft: maize grits and flour milling with germ extraction plant processes raw corn into grad maize grits, flour, germ, feed meal by cleaning, measurement, hulling, polishing, milling.
Our advantage: When we design the processing craft, fully considering our customer’s practical processing requirement, ensuring the quality of finished products and the continual operation of device to optimize device combining form, decrease power consumption, reduce device operation and finished products packing labor, decrease production management cost, maximum customer’s interests.
Installation structure: The line has simple structure, high adjustability for the field area and the workshop, no special requirements. Effectively cut down the fixed investment; Simple installation, fast construct progress, short construction period, allow our clients to meet the benefits in the shortest possible.
Type | Power (KW) | Power Cost (KW/H) | Weight | Size Requirement (L*W*H)m | Output |
LC-100 | 396 | ≤66 | 100 | 24*7*9 | maize grits: 38-45% maize flour:25-35% maize germ:7-9%(purity≥90%) maize feed meal:19-23% |
LC-150 | 480 | ≤54 | 150 | 32*7*9.5 | |
LC-200 | 768 | ≤66 | 200 | 46*7*11 | |
LC-300 | 1086 | ≤61 | 240 | 42.6*12*25.1 |
The process of making maize grits, flour, germ
Core machine of the production line: high efficient vibrating sifter, gravity destoner, Deerminator, corn hulling machine, corn polishing machine, fine corn grits machine, milling machine, low and high pressure fan, plus dust collector....
1. Raw maize primary cleaning: 1 sifting, 1 measurement; equipped with 1 set of dust catching air net to ensure having a good work environment. (According to customer’s requirement to choose it or abandon it.)
2. Raw maize cleaning: 1 sifting, 2 destoning, 1 magnetic separating; equipped with 2 or 3 sets of dust collecting wind net, ensuring to finish production craft and dust catching.
3. Maize Degermination, grading , germ extraction : 2 degerminations, sifting, 3 germ extraction, skin suction.
1) Degerminating: Crush corn into 4-6 pieces, separating germ from endosperm, ensuring the entirety of germ.
2) Sifting: To grade according to the size of material particles; to guarantee the qualified germ and endosperm to enter into next germ extraction procedure;
3) Germ extraction: According to the gravity of material, separating germ from endosperm by sifting plate and fan;
4) Bran suction: According to the gravity of materials, separating seed coat in the mixture from tiny endosperm trough fan;
4.Polishing, corn grits and flour milling: 2 polishing, corn grits crushing, seed coat suction and milling, sifting
1) Polishing: clean out micro skin on the surface of embryo and germ in the corn;
2) Corn grits: Crush big particle embryo into medium, small particles
3) Sifting: To grade according to the size of material particles, sifting qualified flour
4) Bran suction: According to gravity of material, separating micro skin from grade grits through air;
5) Milling: Mill material into qualified fineness flour, sifting by plansifter;
5. Measurement and packing: Add storage before measurement, manual and automatic electronic packing.
Core machines in the200tpd maize grinding mill prices
1.MSD/Q series Electric/ Pneumatic milling machine
Model | Outline Size (mm) | Weight (kg) | Feed Inlet Outer Diameter (mm) | Feed Inlet Inner Diameter (mm) |
MSD/Q125X30X2 | 2060X1676X2005 | 4650 | φ160 | φ150 |
MSD/Q100X30X2 | 1810X1676X2005 | 3950 | φ160 | φ150 |
MSD/Q100X25X2 | 1810X1526X1955 | 3250 | φ160 | φ150 |
MSD/Q80X25X2 | 1610X1526X1955 | 2850 | φ160 | φ150 |
2.YZSJ Fine corn grits machine
Parameter | Rotor Diameter | Mainshaft Speed | Mating power | Air Volume | Output | Overall Size |
Model | (mm) | (r/min) | kw | m3/h | (t/h) | L×W×H(mm) |
YZSJ50×25 | 500 | 2970 | 15 | 1300 | 2—4 | 1520×555×1080 |
YZSJ56×30 | 560 | 2970 | 22 | 1500 | 4—6 | 1520×615×1080 |
YZSJ56×36 | 560 | 2970 | 30 | 1700 | 6—8 | 1560×615×1080 |
YZSJ56×40 | 560 | 2970 | 37 | 1900 | 7—10 | 1580×615×1080 |
3.Degerminating
4. Bran suction
5.Polisher
6.Double-bin plansifter
7.Mid-pressure network
Corn grits and corn flour:
Packing and shiping
Eatabishing friendship with our customer
If you need more technical information and exactly price, please contact with us freely. Our professional technique team will give you the best service.
Warmly welcome friends come to china to visit our factory!
