Home > Products > tungsten carbide mining tips/buttons > Tungsten carbide router bit for Mining the road Cutting the rock Road digging tungsten carbide button bits
Tungsten carbide router bit for Mining the road Cutting the rock Road digging tungsten carbide button bits
- any as required
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Durable dome shaped tungsten carbide button for snow plow/ snow plough
-
Recommended good quality cemented carbide buttons
-
Tungsten carbide buttons tips turning tool in stock
-
Tungsten spherical carbide buttons drill bits for sale
-
Tungsten carbide button tips turning tool/carbide button bit/cemented carbide buttons
-
Tungsten Carbide Drill Buttons
Product Details
| Place of Origin | Hunan, China | Brand Name | JX | |
| Model Number | JX | Alloy Specification | Tungsten Mining Button |
Product Description
Tungsten carbide router bit for Mining the road Cutting the rock Road digging tungsten carbide button bits
Specification
1.High wear&impact resistance
2.Advanced equipment.
3.A long life time
4.High performance
Application
Tungsten carbide drill bit is widely used in mining, sand,cement,metallurgy and hydropower engineering industries.
Properties & applications of Carbide capbuttons for mining of grade YG11C made by top manufacturer in zhuzhou cemented carbide base are available
| Grade | g/cm3 | TRS MPa | Hardness HRA | Performance & application recommended |
| YG4C | 15.10 | 1800 | 90.0 | Mainly used as small buttons for percussion bits to cut soft and medium hard formations. |
| YG6 | 14.95 | 1900 | 90.5 | For coring crowns, electric coal drill bits, coal cutting picks, oil cone bits and scraping knife bits, used in geological prospecting, coal mining and oil well boring. |
| YG8 | 14.80 | 2200 | 89.5 | For coring crowns, electric coal drill bits, coal cutting picks, oil cone bits and scraping knife bits, used in geological prospecting, coal mining and oil well boring. |
| YK05 | 14.95 | 2500 | 90.5 | Mostly used as the buttons of small and medium sized percussion bits and as the inserts of rotary Parabolic prospecting bits to cut soft and medium hard formations. |
| YG8C | 14.80 | 2400 | 88.5 | |
| YK15 | 14.60 | 2450 | 87.6 | Suitable to strips, conical buttons for rotary percussion-resistant, geological prospection buttons, cut soft and medium hard formations. |
| YK20 | 14.40 | 2500 | 86.8 | Primarily for the buttons and inserts of rotary percussion bits to cut medium-hard and hard formations. |
| YK25 | 14.40 | 2550 | 87.2 | Primarily for the buttons and inserts of rotary percussion bits to cut medium-hard and very hard formations. |
| YG11C | 14.40 | 2700 | 86.5 | Largely for the inserts and buttons of percussion bits and tricone bits to cut medium-hard, hard, and very hard formations. |
| YG13C | 14.2 | 2850 | 86.0 | Primarily for the buttons of tricone bits and inserts of rotary percussion bits to cut hard and very hard formations. |
| YG15C | 14.0 | 3000 | 85.5 | For oil cone drill bits, for medium soft and medium-hard rocks. |
Advantages:
Use 100% tungsten carbide raw material
ISO 9001 Certification
with ten year experience
Advanced technology , automatic pressing , HIP sintering And precision grinding
the tolerance of polish and ground can be +0.005/-0.005m
Contact Details:
Tel:0086-0731-28821498
Fax:0086-0731-22332243-8006
Email:jinxin08(at)
jinxin012(at)
chinacarbide(at)
Add:No.28 Xinhua Road,Zhuzhou City,Hunan Province,China
Relying on the advantages of Zhuzhou and Zigong Hard Alloy Production Bases, the company integrates the production, R&D, technical service and sale of hard alloy products, and is devoted to producing hard alloy products and developing hard alloy precision parts.
All of our tungsten Carbide Products are made from the high-purity Original/Virgin Raw Materials and HIP/Sintered, with very high quality and excellent performances. Also the price is very competitive.
If you have any question for the payment,Please let us know.
Contact Us
- Zhuzhou Jinxin Cemented Carbide Co., Ltd.
- Contact nameCanny Tang Chat Now
- Phone86-731-22332243
- AddressCigu Tang No.9, Hetang district, Zhuzhou, Hunan
