Automatic Hollow Plastic Molding Machine

  Automatic Hollow Plastic Molding Machine

YZJ's small Molding Machine, characterized small size, high speed, stable and energy-saving functions. There are automatic water setting, rotary bottle mouse cutting setting, conveyer belt facility and automatic scrapscollecting system, there are single mould head, double mould heads, three mould heads, four mould heads and six mould heads to be selected, the daily output (24 hours) reaches pproximately 20,000 to 120,000; it can produce 0.01-1L plastic hollow products.

 YZJ small Molding Machine

lastic Processed          LDPE/HDPE/PP/PETG/PC/PVC/PS

Application              Plastic bottles, plastic Containers ,barrels, jars, tool Cases & Bags , profiled hollow parts,

 hollow chairs, oil tanks for automobile, plastic panel

Packaging:               Wooden case

Detailed Product Description

Features:
1) For container up to 160 liters capacity
2) Accumulating die head single station high performance continuous extrusion blow molding machine
3) Hydraulic proportion control with parts from YUKEN
4) PLC electricity digital control from Siemems with MPT data setting unit
5) Inverter with harden surface gear box
6) Effective energy saving screw design
7) Central feeding die head overcomes welding line problem
8) Large arm and joint operation type clamping unit with large and uniform clamping force
