3000kg per Hour Pet Bottle Recycling Machine Crush Wash Dry Line
US$ 9,500 - 17,800
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
pet bottle recycling machine
Automatic Grade:
Automatic
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Epe Foam 1000kg/h Pet Bottle Recycling Machine PlanUS$ 15,000 - 60,000MOQ: 1 Set -
Energy Saving High Efficiency Double Stage Pet Bottle Recycling and Washing LineUS$ 15,000 - 60,000MOQ: 1 Set
-
Double-shaft Plc Control System Waste Pet Bottle Recycling MachineUS$ 15,000 - 60,000MOQ: 1 Set
-
Double-shaft Pet Bottle Plastic Bottle Recycling MachineUS$ 15,000 - 60,000MOQ: 1 Set
-
Double-shaft Epe Foam Pet Bottle Recycling and Washing MachineUS$ 15,000 - 60,000MOQ: 1 Set
Condition
New
Application
pet bottle recycling machine
Automatic Grade
Automatic
Production Capacity
500-3000Kg/H
Place of Origin
Sichuan, China
Brand Name
YZJ
Model Number
YZJ-500/1000/2000/3000
Voltage
380V 50HZ(customerized)
Power(W)
80-280KW
Dimension(L*W*H)
35000*4000*3000
Weight
10-30T
Certification
ISO&SGS&CE&BV
Warranty
12 months
After-sales Service Provided
Engineers available to service machinery overseas
Product Description
1.Production Capacity: 500-3000Kg/h;2. Ratio of removing water:≥ 98% ;3.We can design the machines exactly according to Customers' requirments.
Product Detail
| Electric elements | SIEMENS TECO Schneider Omron Delixi |
| Machine material | Q235 or stainless steel 304 |
| Other name | PET bottle recycling machine |
| Other name two | PET bottle recycling plant |
| Other name three | PET bottle washing line |
| product keywords | epe foam new design waste pet bottle recycling machine |
Features:
| No | Units | Describtion |
| Model | YZJPET-500/1000/2000/3000 | Capacity: 500/1000/2000/3000kg/h |
| 1 | Bale opener | Size of processing package:<1400mmx1600x1000mm |
| 2 | Belt Conveyor | PVC Belt,adjustable height,removable wheels |
| 3 | Label remover | Air blower type,removing ratio:>95%; |
| 4 | Sorting platform | With metal detector ,6000mm |
| 5 | Belt Conveyor | PVC Belt,adjustable height,removable wheels |
| 6 | Crusher | with the force feeding pressing device |
| 7 | Screw feeder | 3kw |
| 8 | Vertical Hotwashing boiler | 1600m(dia)x2100m(height) |
| 9 | Screw feeder | 3kw |
| 10 | High speed friction washer | 4000mm |
| 11 | Floating washing tank | 4000mmx1200mmx1500mm |
| 12 | Spraying washing tank | final washing |
| 13 | Dewatering machine | Ratio of removing water:≥ 98% |
| 14 | Air Pipe dryer | Heating by resistance |
| 15 | Storage silo | 3500mm(height)x1200mm(diameter) |
| 16 | Control box | SIEMENS/TECO Inverter,Schneider/Omron/ Delixi contactor etc; |
Quality assurance:
1.CE;
2.ISO9001:2008;
3. We have joined the Alibaba trade assurance system.
Contact Us
Sally ,General Sales Manager
SICHUAN ZIYANG YAZHIJIANG PLASTICS INDUSTRY CO.,LTD
Houjiaping Industrial Park,Yanjiang Phone: 0086 2885214663
District, Ziyang city,Sichuan Province. yzjsally(at)
Skype:sally.yzj , Website: ,
Packaging & Shipping
PACKAGE:
Standard export wooden bo packing.
DELIVERY TIME:
3-30 days after confirming order(payment),detail delivery date should be decided according to production season and order quantity.
