Help CenterHigh Quality Wood Pellet Machine for Making Pellets
Related Products
-
High Capacity Wood Pellet MillUS$ 9,888 - 20,998MOQ: 1 Set -
Automatic CE Certification Wood Pellet MillUS$ 9,888 - 20,998MOQ: 1 Set
-
Cheap Small Wood Pellet MillUS$ 9,888 - 20,998MOQ: 1 Set
-
Competitive Price Ring Die Wood Pellet MillUS$ 9,888 - 20,998MOQ: 1 Set
-
CE Approved Bioenergy New Design Wood Pellet MillUS$ 9,888 - 20,998MOQ: 1 Set
1.specialized in Wood Pellet Mill:
1)Ring die and gear drive type
2)wood pellet machine without conditioner
3)Ring die pellet mill is far superior to flat die technology
4)Gear drive is much better than belt drive,
5)Includes one ring die and a set of rolls
2. Work principle of wood pellet mill machine:
1). Wood pellets machine use the material its own weight, vertical granulating chamber into the mode of the plate, and pressure roller directly to press the material into the model hole vertically.
2). Wood pellets machine under the pressure of pressure roller continuous, and the material in the model hole after pressing, in the form of pellet, eventually sent to the material feeding plate mouth.
3).The machine structure: including motor and reducer, granulating machine three parts.
3.Product Features:
1).The wood pellet mill is special manufacture of feeding structure, it’s feeding uniformity and reliable, design for pressing all kinds of wood.
2).Main drive adopts high accurate gear drive , the die adopts quickly unload anchor ear type, the capacity increase 15% than belt drive.
3).Te main driving system with high quality bearing that imported form Sweden and Japan, to make sure drive with higher efficiency, steady running and reliable.
4).The alloy steel die adopts international advanced equipment and processing &manufacturing, with long working life, smooth pellet, high quality.
5).The international advanced falk flexible coupling, with impact structure, safety, low noise, low malfunction.
6).Pellet machine With high performance permanent magnet device.
4. Specifications
NO |
NAME |
Model |
||||
SZLH32 |
SZLH35 |
SZLH40 |
SZLH42 |
SZLH508 |
||
1 |
Capacity (wood pellet ) |
0.1-0.3 |
0.3-0.5 |
0.5-0.8 |
0.8-1.5 |
1.5-2.0 |
2 |
Power |
37 |
55 |
70/90 |
110 |
132/160 |
3 |
Screw feeder Power |
0.55 |
0.55 |
0.75 |
0.75 |
0.75 |
4 |
Pellet size |
φ6, φ8 |
φ6, φ8 |
φ6, φ8,φ10 |
φ6, φ8,φ10,φ12 |
φ6, φ8,φ10,φ12 |
5 |
No. of press roll |
2 |
2 |
2 |
2 |
2 |
6 |
Outer diameter of press roll |
146 |
165 |
190 |
206 |
222 |
7 |
Mashing rae(%) |
≤12% |
≤12% |
≤12% |
≤12% |
≤12% |
8 |
Dimension(mm) |
2006*800*1300 |
2165*895*1450 |
2302*970*2105 |
3150*1100*1650 |
3200*1300*1850 |
9 |
Weight(t) |
2.1 |
2.5 |
2.8 |
3.1 |
3.5 |
