specialized in Wood Pellet Mill
1.specialized in Wood Pellet Mill
1)Ring die and gear drive type
2)wood pellet machine without conditioner
3)Ring die pellet mill is far superior to flat die technology
4)Gear drive is much better than belt drive,
5)Includes one ring die and a set of rolls
2.A large selection of stainless steel or alloy steel dies for wood pellet mill
1) Driven with heavy- duty gearbox construction can produce continuously in most adverse condition.
2) The imported key elements are of high performance with long life and low maintenance cost.
3 )The key parts are made of alloy steel to be very strong and malleable. Die is made of stainless steel.
4 )Pellet machine is widely used in the granulation of wood, straw, rice husk and other biomass sources.
3. wood pellet mill Features
1). Highly efficient one step gear transmission drive ensures maximum utilization ratio of energy.
2). Full stainless steel feeder; Variable-pitch anti-arch structure; Imported frequency converter control.
3). LL stainless steel conditioner extends the conditioning and cooking time. Axial steam spraying port, improving feed cooking efficiency.
4). High precision driving main gear and pinion shaft adopt the carbonizing quenching and hard tooth surface grinding technology, resulting in smooth driving, low noise and long service life.
4. wood pellet mill Specifications
NO |
NAME |
Model |
||||
SZLH32 |
SZLH35 |
SZLH40 |
SZLH42 |
SZLH508 |
||
1 |
Capacity (wood pellet ) |
0.1-0.3 |
0.3-0.5 |
0.5-0.8 |
0.8-1.5 |
1.5-2.0 |
2 |
Power |
37 |
55 |
70/90 |
110 |
132/160 |
3 |
Screw feeder Power |
0.55 |
0.55 |
0.75 |
0.75 |
0.75 |
4 |
Pellet size |
φ6, φ8 |
φ6, φ8 |
φ6, φ8,φ10 |
φ6, φ8,φ10,φ12 |
φ6, φ8,φ10,φ12 |
5 |
No. of press roll |
2 |
2 |
2 |
2 |
2 |
6 |
Outer diameter of press roll |
146 |
165 |
190 |
206 |
222 |
7 |
Mashing rae(%) |
≤12% |
≤12% |
≤12% |
≤12% |
≤12% |
8 |
Dimension(mm) |
2006*800*1300 |
2165*895*1450 |
2302*970*2105 |
3150*1100*1650 |
3200*1300*1850 |
9 |
Weight(t) |
2.1 |
2.5 |
2.8 |
3.1 |
3.5 |
