Small Hammer Wood Chips Crusher Machine
1. Wood Chips Crusher Machine Brief Introduction of Wood Chips Crusher Machine
Wood chips crusher machine is a machine which our factory latest researched and developed.
Specially used in Orchard garden , Botanical garden, Landscaping department;
wood, tree trunk, tree branch, straw, bamboo stick etc;
wooden piece, small tree branch, leaf, tree bark, feedstuff and chemical material etc material;
Orchard garden , Botanical garden, Landscaping department;( Trimmed branches, trunk, leaf can be crushed as fertilizer .)
Machine can installed on the cart or farm vehicle;
Engine can be electromotor,diesel engine,gasoline engine,both of them are ok for working;
Crushing type can be mobile and fixed-line( two-way for choice).
3. Structure of Wood Chips Crusher Machine
Wood chips crusher machine is mainly composed of four parts such as principal machine, coupling, bottom frame and motor, etc,
in which the principal machine of crusher machine is composed of cutter head, upper and lower covers, feed inlet and outlet, etc.
4. Functions and Usage of Wood Chips Crusher Machine
Use the wood chip crusher to crush wood into chip;
Use the chip dryer to take out the moisture of chip;
Use the Chip Forming Machine to press chip into stick;
Use the wood charcoal bake stove to bake the stick into charcoal;
Then use the wood chip crusher again to break the charcoal into powder;
Use the powder molding machine to press the charcoal powder into all kinds of shape(you can customize many kinds of mould);
Use the packing machine to package the shaped charcoal.
(You can choose it base your raw material,final product and wanted capacity)
5. Warranty of Wood Chips Crusher Machine
One Year (Calculated from the goods arrived the destination port.) If any parts (excluding easily damaging parts) are found defective in quality in the first year, we shall replace it free-of-cost.
After one year, parts can be replaced on favorable payment basis. We can send our engineer to provide the installation and trial run in your place.
But the relevant cost shall be bear in your account (round trip air ticket, board and lodging).
Our professional service includes: Free training, Guidance Installation and Debugging.
If you have any question, please contact us freely. Our after-sales service team on-line will do the best to accomplish your sincere requirement on time.
6. Main Technical Parameter of Wood Chips Crusher Machine
Model |
500 |
600 |
700 |
800 |
900 |
1000 |
Cutter Head Dia.(mm) |
450 |
600 |
650 |
750 |
850 |
950 |
Length of Knife (mm) |
100 |
150 |
200 |
230 |
260 |
300 |
Feed Opening Size(mm) |
180x200 |
200x200 |
200x250 |
250x300 |
300x400 |
400x500 |
rmp(r/min) |
2600 |
2500 |
2600 |
2300 |
2000 |
2000 |
Power(kw) |
7.5 |
11 |
15 |
22 |
37 |
45 |
Capacity(kg/h) |
300 |
600 |
800 |
1500 |
3000 |
4000 |
