Specifications
1)Simple structure2)Environmental protection,save energy
3)More safe for worker
4)environment-friendly
The kiln is the main equipment for calcining high-grade cement chamotte in cement plants and its function is calcining raw material into cement clinker. Besides,the kiln also widely used in ferrous metal, non-ferrous metal, metallurgy, fire-proof material, chemical industry, environmental protection and other industries.
Technical Parameters:
Type | Specifications (m) | Inclination (%) | Capacity (t/h) | Rotation Speed (r/min) | Motor Power (kw) | Weight (t) | Remarks |
Straight Rotary Kiln | Φ1.4×33 | 3 | 0.9-1.3 | 0.39-3.96 | 18.5 | 47.5 |
|
Φ1.6×36 | 4 | 1.2-1.9 | 0.26-2.63 | 22 | 52 |
| |
Φ1.8×45 | 4 | 1.9-2.4 | 0.16-1.62 | 30 | 78.2 |
| |
Φ1.9×39 | 4 | 1.65-3 | 0.29-2.93 | 30 | 77.59 |
| |
Φ2.0×40 | 3 | 2.5-4 | 0.23-2.26 | 37 | 119.1 |
| |
Φ2.2×45 | 3.5 | 3.4-5.4 | 0.21-2.44 | 45 | 128.3 |
| |
Φ2.5×40 | 3.5 | 9.0-10.5 | 0.44-2.44 | 55 | 149.61 |
| |
Φ2.5×50 | 3 | 6.25-7.4 | 0.62-1.86 | 55 | 187.37 |
| |
Φ2.5×54 | 3.5 | 6.9-8.5 | 0.48-1.45 | 55 | 196.29 |
| |
Φ2.7×42 | 3.5 | 10.0-11.0 | 0.10-1.52 | 55 | 198.5 |
| |
Φ2.8×44 | 3.5 | 12.5-13.5 | 0.437-2.18 | 55 | 201.58 | Suspended pre-heating kiln | |
Φ3.0×45 | 3.5 | 12.8-14.5 | 0.5-2.47 | 75 | 210.94 |
| |
Φ3.0×48 | 3.5 | 25.6-29.3 | 0.6-3.48 | 100 | 237 | Kiln with precalciner | |
Φ3.0×60 | 3.5 | 12.3-14.1 | 0.3-2 | 100 | 310 |
| |
Φ3.2×50 | 4 | 40.5-42 | 0.6-3 | 125 | 278 | Kiln with precalciner | |
Φ3.5×145 | 3.5 | 25 | 0.46-1.38 | 2×75 | 830.38 | Wet Kiln | |
Φ3.5×54 | 4 | 58-65 | 0.39-3.54 | 220 | 360 | Kiln with precalciner | |
Φ4.0×60 | 3.5 | 78-85 | 0.6-3.2 | 315 | 512.4 | Kiln with precalciner | |
Φ4.5×100 | 3.5 | 50-70 | 0.86-2.57 | 2×200 | 912.9 |
|
