Professional Chicken / Cow Manure Dryer
1.Chicken manure dryer Application
This kind of dryer is designed for high moisture material, such as more than 65% moisture. The same as Chicken manure, cow manure or pig manure. This dryer is different from other normal dryer, there is a inner mixing shaft to mix plup to better drying. And this type dryer is not very long, it is shorter than normal dryer. This can save your area, and the Drying efficiency is very high. The plup will be in dryer 30-50 mins more or less. You can adjust the speed. As normal, the drying working time is 24hours is better, our smallest model the output capacity is 600- 800kg/h, the largest one is 4.5t/h. And the outlet moisture is less than 15%.
2. What the chicken manure rotary drier consist of?
The dryer include shell, lifting blade, mixing shaft, Frequency conversion motor, reducer, gear ring, roller ring and Overall support.
3. What fuel you can use to heat the rotary drier
You can use coal, natural gas, oil, biomass pellet to be fuel for this manure dryer. You should build a burning room to adjust hot air temperature. Normal temperature is 450-550C
4. What kind of corollary equipment do you build for manure dryer
A. Dewaterer. The raw manure moisture is more than 70%, before drying, you need this dewaterer to reduce the water content to be . This can save the fuel consumption, and Improve the efficiency of drying.
B. Transfer system: belt conveyor or screw conveyor. We suggest use screw conveyor for this manure, it can mix manure before feeding.
C. Dust catcher system: As normal can use cyclone catcher, and we also suggest to use wet-filter to Reduce odor.
D. Burning system+hot air room. The fire can not be in dryer directly, so you should build a hot air room with refractory bricks, then use fan blower to waft hot air to dryer.
5. Manure Dryer Main Technical Parameter
Drying capacity | 500-800kg/h | 1000-1500kg/h | 1500-1800kg/h | ≥2500kg/h |
Rotation speed&power | 3-4rmp,4kw | 3-4rmp,5.5kw | 3-4rmp,10kw | 3-4rmp,15.5kw |
Crushing spindle speed&power | 150-250rmp,3kw | 150-250rmp,4kw | 150-250rmp,4kw | 150-250rmp,5.5kw |
Draught fan power | 7.5kw | 11kw | 15kw | 18.5kw |
Coal consumption | ≤70kg/h | ≤110kg/h | ≤170kg/h | ≤220kg/h |
Floor area | ≥80m2 | ≥100m2 | ≥120m2 | ≥150m2 |
Dryer weight | 4T | 6T | 12T | 19T |
6. Cooperation about chicken manure dryer
We have sold dryer and whole set of machinery to many countrie, We are the professional manufacture to produce the manure dryer. If we have more information from you, we will give you the competitive quotation. We hope for making cooperation with you.
The whole plant machinery size are large as normal, so we will use Waterproof cloth to pack all of them. The motor, gear box or other easily damaged parts, we will put them into box. We have a professional shipping department, they will try them best to save your container quantity. You can trust us .
Our equipments are good quality and have long life time, our QC will control quality.
Henan Hongke Heavy Machinery Co., Ltd. . is located in Henan Province which is the cultural base of the central area of China. We are a mining machinery manufacturing enterprise that integrates scientific research, production and marketing. We are a newly-risen dazzling star in China's machinery industry with the development of market economy.
Our manufactory is a high-tech enterprise that specializes in the research and production of rotary kilns, driers, and crushers. Our major products, for example, rotary kilns, Raymond mills, a series of crushers, stone crushers, and a series of screens, jaw crushers, hammer crushers, impact crushers, cone crushers, and sand making machines, rank highly in the domestic market and some products have reached international advanced level.
