Choose GEC,choose high quality!
GEC brand specialized in continuous grout plant for construction industry
GGP250/350/100PI-D Grout Station /plant is a full hydraulic diesel driven combination of mixer, agitator and grout pump, it is specially design for continuous cement mixing and grouting in ground/underground engineering. It can fast mix water, cement and additive, then the mixed slurry can be stored into a 350 liters agitator, thus the mixing work can continuously be done.
1. Compact size, It is combination of mixer, agitator and piston grout pump in one base frame;
2. Yuken relief valves and directional valves for hydraulic system of grout pump;
3. Butterfly valve of mixer and agitator;
4. Oil temperature gauge can automatically control cooler fan working in normal temperature range, if temperature is too high, the machine will stop work automatically;
5. Operation and maintenance are simple;
6. With ISO, CE certificate.
GGP250/350/100PI-D Grout Plant technical data:
Description | Data |
Grout Station type | GGP250/350/100PI-D |
Mixer Volume | 250L |
Mixer production(w/c ratio=1) | 4 m3/h |
Circulation capacity | 1200l/min |
Suitable W/C Ratio | 0.5 to 1 |
Agitator Volume | 350L |
Agitator Speed | 36rpm |
Water tank | 60L |
Grout Pump Type | GDH90 |
Grout pump output(Max.) | 100L/min |
Grout pump work pressure | 10MPa |
Grout Station Overall dimension | 3300x1650x1500mm |
Grout Station Weight | 1400kgs |
Note: GGP250/350/100PI-D is a combination of mixer, agitator and grout pump in one base frame | |
We also have the following products for option:
GMA400-700 grout cement mixer and agitator
GDH70 and GDH90 piston type high pressure hydraulic drive grout pump
Trade assurance advantages:
1. Quickly lock trusted seller, saving time and energy;
2. Reduce the risk of online purchasing;
3. If there is a trade disputes, you can complain to Alibaba and get benefits compensation.
We are a member of trade assurance on Alibaba, and our trade assurance amount is USD78000.00 Through trade assurance you can 100% payment refund up to trade assurance amount for orders not meeting agreed Delivery or Quality terms.
Certifications of our company:
Factory
1. Q:How to choose suitable type grouting pump?
A: Suitable type will be recommend according to your project, output, pressure etc. factor.
2. Q: What's the project of the grout pump would be used for?
A: pressure grouting in tunnel, mining engineering, dam, foundation engineerig of bridges, building, and other different kinds of underground engineering.
3. Q: You are factory or trading company?
A: Gaode Equipment is has our own factory and technology team, also could be according to your demands to offer the best solution.
4. Q: What's the delivery time?
A: For common type: in one week;
If customize: need 3-4 weeks
If you have any question please feel free to contact me.
Gaode Equipment Co.,Ltd.
Tel:+86-371-55951210 Fax:+86-371-63526676
Skype: lena.liu8
Whatsapp&viber: 86-15903613994
Thank you for your time and Welcome to Visit our factory!
