CLC Light Weight Foam Concrete Pump
Working principle:
GH series industrial hose pump (squeeze pump)/concrete pump/grout pump consists mainly of pump house, rotor, roller, idle roller, squeeze tube and driving unit. The squeeze hose is U-shape in pump house, when rotor drives roller to rotate, hose is deformed. After the roller rotate, the deformed hose recover by its elasticity. Thus the negative pressure in this hose is generated, sucking slurries, and discharging through outlet under roller’s push, finally forms pressure conveying of slurries.
Technical Description:
Type |
GH76-770B |
Max. ouput |
14m3/h |
Rotation |
35 RPM |
Squeeze hose ID |
76mm |
Working pressure |
25 bar |
Voltage |
3 phase, 220V, 60HZ |
Power |
18.5 KW |
The Explanation of Model
GH XX-XXX X
XX: the inner Diameter (mm) of pump tube
XXX: the rotary diameter (D) of pump house
X: gearbox type:
Gearbox A means cycloidal decelerator gearbox,
Gearbox B means Helical--bevel gear units (SEW technical )
Gearbox C means sprocket chain transmission
More infomation about the order:
Purchase Order
Bank slip
Made the GH76-770B pumps:
Bill of Lading:
We can according to your demands tp design the pumps in different output, pressure:
There are severl hose for choose
Gaode Equipment Co., Ltd, short name Gaodetec, Since 1998, we have become main supplier of pump head for one of world’s famous hose pump manufacturer. From recent years, we are also providing matched hose pumps for TBM machine manufacturer in China. Our hose pumps are widely applied in architecture, underground construction, petrochemical industry, metallurgy, food industry, ceramic, mining, water treatment, pharmacy, and papermaking.
1. Q: What's the output of hose pump?
A: 60-42000L/h, if need, we also ca according your demands to redesign the pump?
2. Q: What's the running parts?
A: The squeeze hoe is the only consumpation part.
Now we have three types hose for choose, Chinese hose, Britain hose, and Trelleborg hose.
3. Q: What's the filed of the pump applied in?
A: Our hose pumps are widely applied in architecture, underground construction,
petrochemical industry, metallurgy, food industry, ceramic, mining, water treatment, pharmacy, and papermaking.
4. Q: Whether can according customer's demands customized?
A: Of course. But we need to make clear the following points: what's project will use the pump do? What's the output and pressure do you need?
5. Q: Whether can only offer pump head?
A: Of course. we can offer pump hear without gearbox and electric motor. And also can make OEM for you.
6. Q: Payment item?
A: TT, 30% deposit ,70% before shipment.
L/C at sight (high bank charge, not suggest , but acceptable )
