Chinese Soil Seeds Spraying Machine for Greening

Chinese Soil Seeds Spraying Machine for Greening thumbnail-1
Chinese Soil Seeds Spraying Machine for Greening thumbnail-2
Chinese Soil Seeds Spraying Machine for Greening photo-1
Chinese Soil Seeds Spraying Machine for Greening photo-2
US$ 10,000 - 30,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Seeder Machine, soil seeds spraying machine
Application:
for soil grass spraying and greening
Contact Supplier Request Quote Chat Now
Zhengzhou Gaode Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or other
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Seeder Machine, soil seeds spraying machine
Application for soil grass spraying and greening
Use for soil grass spraying and greening
Brand Name GEC
Model Number PB series grass seeding hydroseeder
Weight 2650kg
Dimension(L*W*H) 4600*2200*2400mm
After-sales Service Provided Engineers available to service machinery overseas

Chinese soil seeds spraying machine for greening

Product Description

 spray seeding is more and more applied in road greening. The application of seeding spraying technology in vegetation restoration and slope protection project.

    PB series artificial soil spraying machine involves in planting permanent vegetation, spraying slurry, slope protection, grassing and erosion prevention.
    Soil spraying machine driven by single diesel, electronic control, easy operation, especially suitable for outdoor conditions, applicable to all kinds of rock slope, hard soil, poor soil, acidic soil, arid zones, clay soil and coastal dam.etc
Feature of  soil seeds spraying machine for greening
    1. The material of main structure is made of high quality structural steel. No matter how worse the conditions are, it ensure seeder sturdy and solid. And it has reasonable, generous appearance. Painted with imported painting to guarantee of three-year no fading.
    2. Advanced technology, it even works for mud materials which have poor mobility, no blocking, and no stopping, well adaptation of various materials, big output pressure.
    3. Two mixing models, blades mixing and circular spray, are powerful enough to ensure the spraying mixture in the planting process is in fully suspended and fully mixed stated, evenly emitting the mixture of raw materials at one time.
    4.It has strong power, the maximum head can be above 60m, and be equipped with many types of spraying guns, which extend the maximum operation scope from 200m to 300m; fan-shaped spray nozzle or mist spraying is more suitable for colse-distance planting to meet various requirements.
    5.This machine has wide usage, not only can be applied in spraying planting for rice, grass, tress, flowers, seeds, and other crops, but also in irrigation, fertilize, pesticide spraying and other daily care, soil improvement work. This machine can also mix different materials like seeds, fertilizer, soil conditioner, seed adhesives, moisturizer, straw, fiber covering materials, yellow soil, red soil, sandy soil and clay, evenly emitting slurry materials with big proportion, high and super concentration.
     6. Our soil spraying machine can also use as a hydroseeder.
 Chinese soil seeds spraying machine for greening
Technical data

Model

PB4083

PB6083

PB8083

Diese engine

LRC4108T

LR4A3Z

LR4A3Z

Power

63kw

83kw

83kw

Tank capacity

4m3

6m3

8m3

Output

1350L/min

Output pressure

8kgf/cm2

Max.Solid Content

Volume ratio 30%, weight ratio 60%

Max.aggregate

20mm

Mixing mode

Hydraulic infinitely variable, blades mixing and circular jet mixing

Rotating speed of mixer shaft

0-110rpm

Max. horizontal conveying distance

38-45m with gun

100-120m with hose

Max. vertical conveying distance

40m with gun

80m with hose

Spraying guns type

Fixed standing gun and pipe gun

Height of fence

800mm

Net weight

2650kg

3200kg

Dimension

4600*2200*2400mm

5500*2200*2500mm



 Chinese soil seeds spraying machine for greening

Date sheet of our diesel engine:



Model

LR4A3Z

Type of diesel engine

Turbo diesel engine, water-cool

Cylinder No.

4 pieces

Cylinder dia.×Piston stroke(mm)

105×125

Capacity(L)

4.33

Rated power/rotating speed(kw/r/min)

83/2400

Max. torque point rotating speed(r/min)

1600-1800

Torque reserve

22-25%

Fuel consumption rate of Declared working condition(g/kw·h)

≤245

Fuel consumption rate of Max.torque working condition(g/kw·h)

≤242

Oil consumption rate of Declared working condition (g/kw·h)

≤1.63

Idle speed(r/min)

1000±30

Cold starting performance

-10°Ccan start easily(without any assist)

High altitude(m)

≤2200

Ambient temperature of diesel engine working

-10°C~40°C

Direction of turning of diesel engine

Anticlockwise(facing power output side)

Net weight(kg)

430



Datailed Images



Chinese soil seeds spraying machine for greening

Chinese soil seeds spraying machine for greeningChinese soil seeds spraying machine for greeningChinese soil seeds spraying machine for greeningChinese soil seeds spraying machine for greeningChinese soil seeds spraying machine for greening

Applicaton

 Chinese soil seeds spraying machine for greeningChinese soil seeds spraying machine for greeningChinese soil seeds spraying machine for greening

Chinese soil seeds spraying machine for greeningChinese soil seeds spraying machine for greening

packaging&shipping

 Chinese soil seeds spraying machine for greening



Related products

 Small hydroseeder ZYP series which soil content ratio is about 20%

Chinese soil seeds spraying machine for greening

FAQ of hydroseeder

We are a professional manufacturer of hydroseeding equipment, in order to recommend you more suitable models, please help us clear about your requirements:

1. what project will you do with hydroseeding equipment? for slope greening projects, lawn or playground?

2. what is max. vertical and horizontal conveying distance?

3. what is soil content ratio in the mixture?

4. which engine do you prefer? Chinese diesel engine Dongfanghong or Huafeng? Cummins or Deutz diesel?

5. do you need soil screening equipments which is usually used with hydroseeding equipments?
