Good performance mobile trailer electric drive concrete pump with forced mixer
1. Description:
Portable concrete pump with mixer is combined by the traditional concrete pump and the mixer together. It achieves full automatic during concrete construction process.
2. Application:
Convey floor heating lightweight foamed cement, mortar, fine aggregate concrete.
Convey greening soil in ecological environment construction.
Convey all kinds of engineering construction in the plain concrete, fiber concrete.
Most suitable for four to six floor buildings, especially in the group buildings, bridges and the small construction sites where need the concrete mixer at the scene.
3. Features:
Mixer and pump in one machine.
Transfer concrete through pipeline. It is fast and safe.
It has small size and suitable for more special environment.
Optional part: cement boom, wireless remote control. This is easy to operate.
Technical data of mobile trailer electric drive concrete pump with forced mixer:
Parameters |
JBT40 L2 |
Main oil pump |
Domestic / Kawasaki 112 |
Mixer model |
JS 500 |
The maximum theoretical delivery output |
40 m3/h |
The maximum theoretical mix output |
28 m3/h |
Vertical pumping distance |
70m |
Horizontal pumping distance |
300m |
Main oil cylinder / Rod * Stroke |
100*70*800 |
Distribution valve type |
S valve |
Main motor |
37kw |
Outlet pressure |
7Mpa |
Hydraulic system type |
Open system |
Oil Cylinder * Rod * Stroke |
100*70*100 |
Delivery Cylinder * Stroke |
200*1000 |
Hopper Capacity * Filling Height |
600*1050 |
Motor voltage |
380V |
Hoist motor |
5.5kw |
Mixing motor |
18.5kw |
Diameter of outlet |
200 |
Max. aggregate size |
Pebble 40mm; Crushed stone:30 |
Weight |
5300kg |
Dimension |
7300*2210*2500mm |
Roller concrete mixer pump:
Diesel and electric trailer concrete pump:
Small concrete pump which could pumping concrete and spray concrete.
small peristaltic pump for pumping and spraying concrete:
We are a professional manufacturer of concrete pump machine, in order to supply a more suitable concrete pump for you, please help us clear on your requirements:
1. what is max.aggregate?
2. what is pump output ?
3. what is nveying distance(vertical and horizontal)?
