Anchorage for prestressing work. In post-tensioned concrete, anchorage anchors play a very important role. The effect of pre-stressing depends on the load that the anchors allow, and anchors’ capability decides the security of the post-tensioning.

Bridge Concrete Anchor Prestressed Flat Stress Anchor

Descriptions:

GBM15 (13) series of  Bridge Concrete Anchor Prestressed Flat Stress Anchor

1. High performance with good quality

2. Used for railway, bridge, highway, buildings

3. Flat or slab anchor systems

4. We can manufacture all kinds of prestressed anchor and equipment according to your requirement and drawings.

Applications:

Bridge Concrete Anchor Prestressed Flat Stress Anchor has been widely adopted by modern construction, especially used in pre-tension or post-tension for concrete constructions as building materials, such as bridge construction, railway and highway construction, buildings and channel construction, etc.

Features:

1. GBM15 (13) Bridge Concrete Anchor Prestressed Flat Stress Anchor are used for the strand with diameter of |15.2-|15.7,|12.7-|12.9.

2. If prestressing strand is collocated in plate-type, you can arrange the prestressing strand into flat redial pattern by flat anchorage to avoiding to increasing the thickness of plating.

3. GBM15(13) Bridge Concrete Anchor Prestressed Flat Stress Anchor includes flat anchor plate, working wedge, flat bearing plate, and uses the QYC front-end fixed jack to stressing.

5. The GBM series wedge anchors can work automatically; have a high anchor efficiency and very good performance. They are ease to use, safe and reliable. They are crystallization of large quantity of experiences and scientific research.

6. They are used to anchor prestressing strands from 12.7mm and 15.2mm, 15.24mm.varies from 1 to 22 and we can produce according to your specific requirements.

7. The strength of extension of a single can be up to 2000 Mpa.

Technical parameter:

 Round Anchor:

Bridge Concrete Anchor Prestressed Round Stress Anchor

1.Type: Single-hole, Multi-hole; Circular, Flat

2.Parts: Anchor Ring/Plate, Wedge, Base Plate etc

3. Have a high anchor efficiency and very good performance

4. Easy to use,safe and reliable, Post tensioning and prestressing use

5. We can manufacture all kinds of anchorage and prestressed equipment according to your requirement and drawings.

Bridge Concrete Anchor Prestressed Round Stress Anchor

1. M15 applies to 15.2/15.24mm, 15.7mm pc strand.

2. M13 applies to 12.7mm, 12.5mm & 12.9mm pc strand.

3. M18 applies to 17.8mm pc strand.

4. M22 applies to 21.6/21.8mm pc strand.

5. M11 applies to 10.8mm pc strand.

6. M10 applies to 9.3mm, 9.53mm pc strand.

7. M7, M6, M5 apply to 7.0mm, 6.0mm, 5.0mm spiral ribbed pc wire

Wedge, Anchorage ring, Bearing plate, Bursting reinforcement, Metal Bellows(mental ducts). And we have metal bellows moulding machine and flat pipe machine.

Bridge Concrete Anchor Prestressed Flat Stress Anchor

Bridge Concrete Anchor Prestressed Round Stress Anchor
