GYJ series prestressed steel strand extrusion machine hot sale
GYJ series prestressed steel strand extrusion machine hot sale
Descriptions:
1. We manufacture extruding machine and embossing machine
2. GYJ series extrusion machine is the special equipment of making the P fixed- end anchorage
3. YH30 embossing machine is the special extruding equipment of making the fixed-end anchorage, mainly used for extruding the fixed-end of Prestressing strands into pear-shaped scattering shape.
4. For prestressing and post-tensioning use.
5. Good quality with high performance
Features:
For GYJ extruding machine:
Extruding Machine is a professional equipment mainly used to extrude prestressed cable and make them become grip Wrap type anchors. it is applied for single end anchoring, such as Φ12-Φ15.7 prestressed cable. This method is very simple and this kind of equipment is easy to operate, high efficiency with extruding 20 or 30 pieces of anchors per hour.
For YH30 embossing machine:
YH30 Embossing Machine is a special equipment which is applied in multistrand fixing and H type anchoring system. After replaced the wedge, it can be used for the other specification of steel strands. YH30 type embossing machine is small in size, light, and easy to operate.
Technical parameter:
The technical parameter of GYJ extrusion machine:
parameter table of GYJ extrusion machine | |||||||
Model | Rated extrusion | Extrusion | Extrusion | Return area | Stroke of | Mass | Overall |
pressure | hydro-cylinder | area of piston | of piston | extrusion | dimension | ||
KN | Mpa | m² | m² | mm | kg | mm | |
GYJ500 | 495 | 63 | 7.85 ×10-³ | 4.5×10-³ | 150 | 70 | 760×200×200 |
GYJ600 | 565 | 50 | 1.13×10-² | 4.95×10-² | 150 | 50 | 605×195×195 |
The technical parameter of YH30 embossing machine:
Parameter table of YH30 embossing machine | |||||||
Model | Rated stressing | Oil | Return area | Extrusion area | Stroke of | Mass | Overall |
pressure | pressure | of piston | of piston | extrusion | dimension | ||
KN | Mpa | m² | m² | mm | kg | mm | |
YH30 | 30 | 43 | 0.425×10-³ | 0.707×10-³ | 70 | 11 | 560×155×215 |
Application:
It has been widely adopted by modern construction, especially used in pre-tension or post-tension for concrete constructions as building materials, such as bridge construction, railway and highway construction, buildings and channel construction, ect.
