Flower Tea Packing Machine
US$ 18,000 - 30,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage, Chemical, Food, Other, Beverage, Chemical, Food, Machinery & Hardware
Packaging Type:
Bags
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Guaghzhou/Shenzen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Back Sides Sealing Automatic Blueberry Sauce Packaging MachineUS$ 3,500 - 4,500MOQ: 1 Set -
Case Bottom Sealer MachineUS$ 1,000 - 2,000MOQ: 1 Set
-
Adhesive Tape Carton Box Sealer MachineUS$ 1,000 - 2,000MOQ: 1 Set
-
High Quality NJM-520 Balance Biscuit Packing Machine Cartoon Packing MachineUS$ 1,500 - 12,000MOQ: 1 Set
-
Hot Sale Pouch Packing Machine Potato Chips Packing Machine Stand up Pouch Packing MachineUS$ 1,500 - 12,000MOQ: 1 Set
Condition
New
Application
Beverage, Chemical, Food, Other, Beverage, Chemical, Food, Machinery & Hardware
Packaging Type
Bags
Packaging Material
Paper, Plastic
Automatic Grade
Automatic
Driven Type
Electric
Voltage
220V/380V
Power
1.25 Kw
Place of Origin
Guangdong, China
Brand Name
AL-Najem
Dimension(L*W*H)
1700*900*2000mm
Certification
CE,SGS,SASO,FORM E, C/O
After-sales Service Provided
Engineers available to service machinery overseas
Flower Tea Packing Machine
Product Description
1.ND-CCFD6 is Automatic Tea Packing Machine,the machine finish bag making,
measuring, filling, sealing, coding and counting full automatically.
2.Measure with volume cup, with 1% error, the bag forming and sealing finished by bag
former.
3.Suitable for packing tea product for 8cm³ per bag packing.
4.6600 bag/hour high out-put.
Tea Bag Packing Machine CCFD6 | Features:
1.Model ND-CCFD6 is our new tea bag packing machine for inner bag and outer bag,the
inner bags with drawing string and tag.
2.Automatic ration filling, heat sealing of innertea bags, automatic plastering of cotton
thread and tags, and cold-sealing of the envelope in the longitudinal direction.
3.The envelope is sealed and packed with paper. This packing machine apply cold press
the Vertical sealing on both sides, with quantitative feeding, heat sealed inside bags,
automatic adhesive the labels and the thread.
4.All the packing machine is made from SS304, clean and safe, easy for cleaning.
5.This model got higher speed, technology very mature, the continuous running make it
very high efficiency.
Tea Bag Packing Machine CCFD6 / Material & Samples:
Tea Bag Packing Machine CCFD6 | Parameters
| Type | C60 | C8I | C8IV | C15 | C10 | D6 | KR66 | T2C | T2A |
| Bag Size(mm) | 50-80 |
|
|
|
|
|
|
|
|
| Flat Bag Size(mm) | L: 40-80 W: 60-90 |
62.5*50 | 62.5*50 | 65*62.5 | 45*60 | 62.5*50 | 60-65 | L:50-75 W:50-75 |
L:60-75 W:55-70 |
| Outer Bag Size(mm) | 100*100 |
|
80*70 | 82*75 | 70*80 | 70*65 | 70-75 | L:80-120 W:75-100 |
|
| Measuring Range | 1.5-10ml | 8cm3 | 8cm3 | 15cm3 | 1-10cm3 | 1-8cm3 | 2-7grams | 3-10ml | 3-10ml |
| Tag Size(mm) | 28*24 | 28*24 | 28*24 | 28*24 | 28*32 | 28*24 |
|
28*28 | 28*28 |
| Thread Length(mm) | 210 | 210 | 210 | 210 | 140±5 | 210 |
|
176 | 170 |
| Packing Speed (Bag/hour) |
3600 | 7200 | 6600 | 6600 | 7200 | 6600 | 2400-3000 | 2100-3600 | 2100-4800 |
| Film Width(mm) | 120;140 160;180 |
|
|
|
75 |
|
180 |
|
|
| Voltage | 220V/380; 50/60Hz | ||||||||
| Power | 1.2Kw | 2.36Kw | 2.36Kw | 2.36Kw | 8.0Kw | 0.75Kw | 1.6Kw | 3.7Kw | 1.6Kw |
| Air Pressure(Mpa) | 0.6 |
|
|
|
6 atm(bar) |
|
0.4-0.7 |
|
|
| Air Consumption(L/min) | 200 |
|
|
|
300 |
|
0.1 |
|
|
| Weight(Kg) | 500 | 720 | 1410 | 1410 | 5000 | 720 | 400 | 500 | 400 |
| Overall Dimensions | 980*880*1980 | 1790*900*2000 | 1688*1330*2205 | 1688*1330*2205 | 3500*1500*2400 | 1700*1000*2000 | 1050*950*2040 | 900*700*1700 | 1800*950*780 |
| Sealing Methods | Pyramidsealing Flat sealing |
3 sides sealing | 3 sides sealing | 3 sides sealing | Double chamber | 3 sides sealing | Round Pods | 3 sides sealing | 3 sides sealing |
| Packing in Box |
|
25,50,100 / 30,60 / 20,40 |
|
|
|
|
|||
