Manufacturer AWS ER70S-6 Carbon Steel Welding Wire
- XINGANG CHINA
- T/T
You May Like
Product Details
Place of Origin | Tianjin, China | Brand Name | X & Z welding wire ER70S-6 | |
Model Number | AWS A5.18 ER70S-6 | Material | Stainless Steel | |
Diameter | 0.8mm 0.9mm 1.0mm 1.2mm 1.6mm | Melting Point | standard | |
Weight | 15kgs/spool | Application | Mainly used for welding low carbon alloy steel, widely used in industr | |
Flux Content | standard |
Product Description
Manufacturer AWS ER70S-6 carbon steel welding wire
carbon steel welding wire
1. Size.:0.8MM, 1.0MM,1.2MM,1.6MM
2. Advantages :excellent welding performance, soft and stable arc, low spatter loss, easy slag removable, higher deposition rate particularly and suitable for all -position welding.
3. Typical application: Metallurgical industry, Bridge building, building industry, shipping industry
4. packing: 15kg/spool (paper box packing) 72 boxes/pallet(1080kg), 23760kg (22pallets), loaded in one 20 feet container
5. Quality certificate: ABS, LR, BV, GL, DNV, KR, CCS .
6.Chemica l Composition and technical data
Chemical Component of Final Production(%) | ||||||||||||
Component | C | Si | Mn | P | S | Cr | Ni | Cu | ||||
Standard | Max.0.12 | Max.0.9 | Max.1.75 | Max.0.030 | Max.0.030 | Max.0.20 | Max.0.50 | Max.0.35 | ||||
Typical Test of Mechanical Property | ||||||||||||
Yield Strength σ0.2(MPa) | Tensile Strength σb(MPa) | Percentage Elongation δ5(%) | impact value (J) | Test Temperature (°C)
| ||||||||
535 | 639 | 25 | 112 | -20 |
Used for welding structures made of carbon steel and low-alloy structural steel with tensile strength higher than or equal to 490MPa. Most widely used for welding some key structures like shipbuilding, mechanical manufacture, pressure vessels, boilers, petroleum machinery, chemical machinery, hoisting machinery, etc.
carbon steel welding wire
15kgs/spool, one spool into a carton
72 cartons per pallet
carbon steel welding wire
Xuzhi company product scope:
(1) Flux cored wire plant project Consulting (including the new factory process design, old factories technology and equipment reform, improve the production efficiency, the new product formula design and development.)
(2) Flux cored wire complete line manufacturing
(3) Hardfacing & stainless steel etc special flux cored wire product manufacture
(4) Provide high quality2roll-type and 3roll-type of roller die cassette for the following types of customers:
1) flux cored wire manufacturer
2) solid wire manufacturer
3) rebar manufacturer
4) Metal products related company, such as: nail making, welding nets, wire rope, reinforcement wire, Electric wire and cable, non-ferrous metal products, etc.)
(5) Produce various specifications and types of wire drawing machines used in metal products processing and manufacturing
(6) Metal products finished product cleaning machine (such as: steel strip cleaning, machinery parts cleaning, glasses cleaning, and more complex shape metal products finished product cleaning)
(7) Metal products auxiliary machine manufacturing (such as: various types of pointing machine)
(8) Food machinery and pharmaceutical machinery manufacturing
carbon steel welding wire
Xuzhi company was founded in 1998. After years of development, now the company already had the mainstream business which shows in the next item.
Except the mother company “xuzhi company”, we have other companies were built according to professional led division, intensive management framework. At present the company development direction is to professional industry chain deep direction. Thus be dedicated to research and development, design.Now TIANJIN THREE WATER is the export company serviced for xuzhi.
carbon steel welding wire
