Pointing machine
Before the wire is pushed through the die hole of wire drawing machine, to enter the wire in the die it should be pointed at starting end, so that it can pass through the die hole easily. The pointed end of the wire is then pulled by means of pull-in tong in order to draw it.
Wire pointing machine is used to point starting end of wire. It has two rollers having different sizes of grooves on their periphery. As the machine starts, rollers rotate in opposite direction of each other. End of the wire to be pointed is pushed between the two rollers which tend to point the wire.
Rollers are made out of high quality alloy steel and are duly hardened and ground to give longer working life.
Max. diameter of drawing Φ6.5mm
Min finished diameter Φ2.5mm
Motor power 3kw
Overall size 520×480×1200mm
Weight 0.2T
Our factory development and production of flux cored wire pointing machine is the flux cored wire production line auxiliary equipment, based on the solid wire pointing machine, according to the characteristics of air cored wire restructuring, especially suitable for flux cored wire pointing.
Tianjin Xuzhi Machinery & Electrical Equipment Co., Ltd. is a high-tech integrated enterprise registered in Tianjin New Technology Industry Area.
Our company owns rich experience of high-tech product development and multitudinous successful model in the aspect of raw material production, research and development, and special-purpose manufacture equipment related to welding material.
A complete set of production equipment manufacturing flux welding wires, related product development capability, scientific management, strong technical consultation as well as professional technical services are our company's key competitive force.
a.) Consultation service before, during, and after sales;
b.) Project planning and design services;
c.) Debugging of equipment until everything is functional;
