New mode polished large capacity mixing storage tank, liqulid preparation vessel
Preparation Vessel,Aseptic Tank,Pressure Vessel,Mixing Tank,Stainless Steel Tank
Introduction
Liquid preparation vessel is for making base liquids before final reaction.
Usually it has an agitator and a jacket outside for input conduction oil.
The oil is heated by electric rods. There are oil inlet, outlet, overflow port, vent port, electric rods port,
and temperature detection port on the jacket.
Features:
1. SS material, can bear high pressure during the process of materials reaction and feeding
2. Good heat-resistance, large range of working temperature (-196~600°C).
3. Good anti-corrosion, not easily get rust
4. Good heat transfer
5. Mirror polish, easy clean without residuals
Specs. Of 500 L. Preparation Vessel (Jhenten)
1- Material of TANK : SUS316L
2- Thickness of shell: 4 -6 mm
3- Working pressure: -1 to 4 Bar
4- Working Capacity Of the Vessel is 500 Liters
5- Working temperature: 121°C
6- Design Temp : minimum 10°C & maximum around 150°C
7-Motor power: 1.5KW 380V 60Hz horizontal type
8- Agitator Speed : 70 – 90 RPM & Agitator type : 2Layers
9-Diameter of TANK: 800mm - 1000mm
10- Height from Floor to Motor Top Of the Agitator =1500 mm
1-Material of heat preservation layer:SUS304 thickness: 3 -5 mm
12- Polishing From Inner Side is Mirror 0.28μm
13.-Polishing From Outer Side is Mirror not more than 0.5μm
14- TWO Rotating Balls ST.ST.316 L inside the Tank For Cleaning
15- At The Tank Bottom We Need Diaphragm Valve With Triclamp Connection
16- Connections ( 316L Triclamp Connections ) for CIP, SIP, Product Circulation + Pressure gauge +
Air Filter,Connection + Safety Valve ( All 1.5 Inch )
17- Sight Glass With suitable Effective Light
18- Man Hole LID with Silicon OR EPDM O ring & Open towards the Agitator motor Side
19- Design & Manufacturing Qualification Document, include Official Certificates Of Tank Materials & Tank Welding Certificates
20- Factory Acceptance Tests ( FAT ) Documents
21- Site Acceptance Test ( SAT ) Documents
22- Installation Qualification Documents ( IQ ) & Operation Qualification Documents (OQ )
23- Grantee Certificate
Main Technical parameters
Parameter |
ZT 300 |
ZT400 |
ZT500 |
ZT600 |
ZT1000 |
ZT2000 |
ZT3000 |
ZT5000 |
ZT10000 |
||||||||||||
Cubage(L) |
300 |
400 |
500 |
600 |
1000 |
2000 |
3000 |
5000 |
10000 |
||||||||||||
Pressure |
Internal bladder |
≤ 0.2Mpa |
|||||||||||||||||||
Insert set |
≤ 0.3Mpa |
||||||||||||||||||||
Power (Kw) |
0.55 |
0.55 |
0.75 |
0.75 |
1.1 |
1.5 |
1.5 |
2.2 |
3 |
||||||||||||
Speed of impeller |
18=200r/min |
||||||||||||||||||||
Outlook size |
Diameter |
900 |
1000 |
1150 |
1150 |
1400 |
1580 |
1800 |
2050 |
2500 |
|||||||||||
Height |
2200 |
2220 |
2400 |
2500 |
2700 |
3300 |
3600 |
4200 |
5000 |
||||||||||||
Heat transfer area |
2 |
2.4 |
2.7 |
3.1 |
4.5 |
7.5 |
8.6 |
10.4 |
20.2 |
||||||||||||
Jhen Ten carries on traditional Japanese production skills and latest Japanese industrial technology to produce filtration products and all kinds process machinery.
In addition to the introduction of new manufacturing methods and the purchase of advanced welding equipment, we are also dedicated to researching the improvement of quality, function and usage life of our products. We have been meeting global demand of high quality &technical support to our clients.Our products cover from all kinds sanitary filter,cartridge filter, bag filter ,mixing tank ,storage tank etc,which have been applied into fields of pharmacy, food & beverage, biological engineering, lab solution laboratories, mineral water, liquor and cosmetics.
No matter the functions, data presentation, material use, welding techniques, QC, or the look of our products have gone through careful design and are strictly comply with ISO9001 and CE standard system.Besides We have obtained the sanitary license and honour of high quality&honesty from authority.
