2" ROTARY PUMP rotor pump for honey gear pump
Rotary lobe pump, is reliable and very reasonably priced
Features
• it is designed to handle viscous or sensitive products with large particulates.
• the butterfly curve of the rotor, ensures a characteristic smooth low shear pumping action.
• this leads to the gentle throughput of delicate and sensitive products, without crushing or breaking them (certain soft fruits in large dice format excepted)
honey gear pump lobe pump
Lobe pumps gear pump are used in a variety of industries including pulp and paper, chemical, food, beverage, pharmaceutical, and biotechnology. They are popular in these diverse industries because they offer superb sanitary qualities, high efficiency, reliability, corrosion resistance and good clean-in-place and steam-in-place (CIP/SIP) characteristics.
Rotary lobe pumps can handle solids (e.g., cherries and olives), slurries, pastes, and a variety of liquids. If wetted, they offer self-priming performance. A gentle pumping action minimizes product degradation. They also offer continuous and intermittent reversible flows and can operate dry for brief periods of time. Flow is relatively independent of changes in process pressure, too, so output is relatively constant and continuous.
How gear pump lobe pumps work
gear pump lobe pump internals
Gear Pump Lobe pumps are similar to external gear pumps in operation in that fluid flows around the interior of the casing. Unlike external gear pumps, however, the lobes do not make contact. Lobe contact is prevented by external timing gears located in the gearbox. Pump shaft support bearings are located in the gearbox, and since the bearings are out of the pumped liquid, pressure is limited by bearing location and shaft deflection.
1. As the lobes come out of mesh, they create expanding volume on the inlet side of the pump. Liquid flows into the cavity and is trapped by the lobes as they rotate.
2. Liquid travels around the interior of the casing in the pockets between the lobes and the casing—it does not pass between the lobes.
3. Finally, the meshing of the lobes forces liquid through the outlet port under pressure.
Lobe pumps are frequently used in food applications because they handle solids without damaging the product. Particle size pumped can be much larger in lobe pumps than in other positive displacement types. Since the lobes do not make contact, and clearances are not as close as in other Positive displacement pumps, this design handles low viscosity liquids with diminished performance. Loading characteristics are not as good as other designs, and suction ability is low. High-viscosity liquids require reduced speeds to achieve satisfactory performance. Reductions of 25% of rated speed and lower are common with high-viscosity liquids.
specifications --- hot sell lobe pumps specification
Model | capacity | gear box speed range | capacity | Power of motor |
L/100cycle | R/min | L/M | ||
D3A-3 | 3L | 200-500 | 300-800 | 0.55 |
D3A-6 | 6L | 200-500 | 600-1600 | 0.75 |
D3A-8 | 8L | 200-500 | 850-2100 | 1.5 |
D3A-12 | 12L | 200-500 | 1300-3200 | 2.2 |
D3A-20 | 20L | 200-500 | 2100-5400 | 3 |
D3A-30 | 30L | 200-400 | 3200-6400 | 4 |
D3A-36 | 36L | 200-400 | 3800-7600 | 4 |
D3A-52 | 52L | 200-400 | 5600-11000 | 5.5 |
D3A-53 | 53L | 200-400 | 7100-14000 | 7.5 |
D3A-66 | 66L | 200-400 | 9000-18000 | 7.5 |
D3A-78 | 78L | 200-400 | 11000-22000 | 11 |
D3A-135 | 135L | 200-400 | 15000-30000 | 15 |
D3A-160 | 160L | 200-400 | 17000-34000 | 18.5 |
D3A-200 | 200L | 200-400 | 21600-43000 | 22 |
2" ROTARY PUMP rotor pump for honey gear pump
