Jacketed kettle used for tomato paste cooking kettle
- Jacketed kettle capacity 50Liter to 600Liter
- Jacketed kettle made of stainless steel with mixer
- Jacketed cooking kettle tilting cooking kettle with scraper
JACKETED-KETTLE-JACKETED COOKING-KETTLE-TILTING-JACKETED-COOKING-POT
A steam-jacketed kettle is similar to a double boiler and cooks large quantities of food by using steam heat. It is designed with both an inner and outer steel wall that cooks the contents inside by releasing steam into the space between the walls. These devices are often used to cook foods like stock, gravy, sauce, or soup, and may be powered by electricity or gas. They come in various sizes, for installation on the floor, countertop, or wall. Steam-jacketed kettles are often used in restaurants and industrial kitchens, where very large amounts of food are prepared daily.
JACKETED-KETTLE-JACKETED COOKING-KETTLE-TILTING-JACKETED-COOKING-POT
All the different styles and sizes of steam-jacketed kettle use steam to cook the contents inside. Most are made from stainless steel, and usually, the steam jacket is permanently filled with treated, distilled water. Since steam encapsulates most of the kettle, it may cook more evenly than a traditional stock pot because it offers a more uniform cooking surface. It also tends to warm contents more quickly than a traditional pan, heated primarily from the bottom.
JACKETED-KETTLE-JACKETED COOKING-KETTLE-TILTING-JACKETED-COOKING-POT
Electricity, gas, or both may supply power to the kettle. A gas fired kettle requires a gas hook up source to operate and may also require electricity if it has automatic ignition. Gas kettles also require a kitchen ventilation system for safety.
50L 100L jacketed kettle specification
200L 300L tilting cooking kettle double layer specification
400L 500L 600L tilting jacketed kettle with agitator and scrapers price
JACKETED-KETTLE-JACKETED COOKING-KETTLE-TILTING-JACKETED-COOKING-POTTechnical parameters:
Model |
50 |
100 |
200 |
300 |
400 |
500 |
600 |
800 |
1000 |
|
Caliber(mm) |
Φ600 |
Φ700 |
Φ800 |
Φ900 |
Φ1000 |
Φ1100 |
Φ1200 |
Φ1400 |
Φ1500 |
|
Depth of Pot(mm) |
400 |
450 |
530 |
630 |
680 |
730 |
780 |
830 |
900 |
|
Heating area(m2) |
0.45 |
0.58 |
1.12 |
1.42 |
1.75 |
2 |
2.3 |
3.2 |
3.9 |
|
Boiling time(min) |
5 |
8 |
11 |
14 |
18 |
22 |
25 |
34 |
40 |
|
Interface size |
Steam pipe |
3/4” |
1” |
2” |
||||||
Condensate pipe |
3/4” |
1” |
||||||||
Working pressure |
≤0.09Mpa/0.25Mpa/0.5Mpa(can be adapted according to customers’ requirement) |
|||||||||
Stirring speed |
36 r/min(can be adapted according to customers’ requirement) |
|||||||||
Stirring power(Kw) |
0.55 |
0.55 |
0.75 |
1.1 |
1.1 |
1.5 |
1.5 |
2.2 |
2.2 |
|
Scraping edge stirring power(Kw) |
0.75 |
0.75 |
1.1 |
1.5 |
1.5 |
2.2 |
2.2 |
3 |
4 |
|
JACKETED-KETTLE-JACKETED COOKING-KETTLE-TILTING-JACKETED-COOKING-POT
Jacketed kettle picture
Buy jacketed kettle, stainless steel jacketed cooking kettle, oil jacketed kettle tilting jacketed product from Wenzhou
We offer best price JACKETED-KETTLE-JACKETED COOKING-KETTLE-TILTING-JACKETED-COOKING-POT, if you need cheapest JACKETED-KETTLE-JACKETED COOKING-KETTLE-TILTING-JACKETED-COOKING-POT, come to us, we are direct manufacture of JACKETED-KETTLE-JACKETED COOKING-KETTLE-TILTING-JACKETED-COOKING-POT.
