tilting jacketed cooking kettle with CE certificate
BRanD nEw jacketed kettle jacketed cooking kettle here are the specifictions of the electric heating jacketed cooking kettle
Model | DG-200 | ||
kettle | diameter | Φ800mm | |
Deepth | 550mm | ||
Capacity (L) | 200 | ||
MAX Mechanical tilt | 90°C | ||
Connection pipes | steam | 3/4" | |
Cool water | 3/4" | ||
Motor power | 0.55kw | ||
Electric-heating power | 18KW/H | ||
Boiling time | ~13 mis | ||
Heat transfer area | 1.13 m2 | ||
Needed heat transfer oil | 55KG | ||
Design temperature | 180°C | ||
MAX working temperature | 151°C | ||
Design pressure | 0.095Mpa | ||
MAX pressure | 0.095 | ||
size | L(mm) | 1100 | |
W(mm) | 850 | ||
H(mm) | 1450 | ||
Price | Electric heating |
| |
we are manufacture of jacketed kettles, we offer cheapest price and best quality tilting jacketed kettle.
if you need more detail informaton of our cooling pot, please let me know
you can send email to us and tell us that what kind of jacketed cooking kettle you need.
such as a 300L jacketed kettle electric heating
or a 200L steam heating tilting jacketed kettle for juice....
BRanD nEw jacketed cooking kettle for apple juice cooking equiment,
