Product Details
Condition: | New | Place of Origin: | Zhejiang, China | Brand Name: | wanyuan |
Model Number: | 500L fermentor | Warranty: | One Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Processing Types: | Other, Juice |
Product Description
stainless steel tank for juice and milk / fermenting tank
Stainless Steel Fermenting Tanks mixing tank with agitator
1. single layer
a. open top slope bottom
b. open top conical bottom
c. conical top and bottom
d. ellipsoidal top and bottom
2. double layer / insulated tank / storage tank
a. open top slope bottom
b. open top conical bottom
c. conical top and bottom
d. ellipsoidal top and bottom
3. 3 layers tank
a. open top slope bottom
coil type / jacket type / heating oil jacket
b. open top conical bottom
coil type / jacket type / heating oil jacket
c. conical top and bottom
coil type / jacket type / heating oil jacket
d. ellipsoidal top and bottom
coil type / jacket type / heating oil jacket
Main Technical Parameters:
Capacity | Rotating Speed | Working Pressure | Experimental Pressure | Motor Power | Operating Temperature |
(MPa) | |||||
100L | 110-220 | 0.15 | 0.30 | 0.37 | ≤1200C |
75L | 110-220 | 0.15 | 0.30 | 0.37 | ≤1200C |
200L | 110-220 | 0.15 | 0.30 | 0.5 | ≤1200C |
300L | 110-220 | 0.15 | 0.30 | 0.5 | ≤1200C |
500L | 110-220 | 0.15 | 0.30 | 0.75 | ≤1200C |
600L | 110-220 | 0.15 | 0.30 | 0.75 | ≤1200C |
800L | 110-220 | 0.15 | 0.30 | 1.1 | ≤1200C |
1000L | 110-220 | 0.15 | 0.30 | 1.1 | ≤1200C |
2000L | 110-220 | 0.15 | 0.30 | 2.2 | ≤1200C |
3000L | 110-220 | 0.15 | 0.30 | 3.0 | ≤1200C |
5000L | 110-220 | 0.15 | 0.30 | 3.0 | ≤1200C |
8000L | 110-220 | 0.15 | 0.30 | 4.0 | ≤1200C |
10m3 | 110-220 | 0.15 | 0.30 | 5.5 | ≤1200C |
20m3 | 110-220 | 0.15 | 0.30 | 5.5 | ≤1200C |
40m3 | 110-220 | 0.15 | 0.30 | 7.5 | ≤1200C |
60m3 | 110-220 | 0.15 | 0.30 | 7.5 | ≤1200C |
100m3 | 110-220 | 0.15 | 0.30 | 10.0 | ≤1200C |
We can make special product according to customer’s request
