Stainless Steel Mixing Tank 500L mixing tank high speed mxing tank LRG-500
- 500 Set / Sets per Month
- ningbo
- T/T
Product Details
Condition: | New | Mixer Type: | Paddle | Product Type: | Fertilizer |
Application: | Liquid | Place of Origin: | Zhejiang, China | Brand Name: | wanyuan |
Model Number: | LRG-500 | Max. Loading Capacity: | 500Liter | Voltage: | 110V / 220V / 380V |
Power(W): | 1.1KW | Dimension(L*W*H): | 900*900*1500 | Certification: | CE ISO |
Warranty: | 12 months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Stainless steel mixing tanks with adjustable speed
mixing tank model: LRG-500
1. Made of stainless steel
2. Mixing milk, juice, or any other viscous liquid
3. Customized mixing tank capacity
Mixing Tank <mixing tanks> mainly made of stainless steel, used for mixing different liquid together.
Also, you can use this mixing tanks to mix liquid and power to make a mixture.
Mixing tanks can be with different mixing speed. Such as 36rpm, 60rpm fixed mixing speed. But due to some production reqeust, you may need the mixing tanks with variable speed, such as 8 to 140rpm, 40 to 200rpm mixing speed, or 200 to 1000 rpm mixing speed. In special reqeust, we can use VFD<Variable Frequency Drive> to meet your special mixing speed request.
Mixing tank paddle inner side of the mixing tank
Wenzhou wanyuan food machinery factory mainly produce stainless steel mixing tanks for milk, juice, beverage, cosmetic, detergent as well as chemical product.
Our Mixing tank capacity can be 50L, 200L, 500L, 2000L or any other capacity you need.
here below is some hot sell mixing tanks check the specification please
volume (L) | Dimension (D× h ) (mm) | Total height (mm) | Diameter Of inlet & outlet | Heat preservation layer (mm) |
500 | 840 × 1000 | 2250 | 38 | 60 |
600 | 920 × 1000 | 2300 | 38 | 60 |
700 | 990 × 1000 | 2300 | 38 | 60 |
800 | 950 × 1220 | 2500 | 38 | 60 |
900 | 1010 × 1220 | 2500 | 38 | 60 |
1000 | 1060 × 1220 | 2550 | 51 | 60 |
1500 | 1160 × 1500 | 2850 | 51 | 60 |
2000 | 1340 × 1500 | 2900 | 51 | 60 |
3000 | 1410 × 2000 | 3400 | 51 | 60 |
4000 | 1620 × 2000 | 3450 | 51 | 60 |
5000 | 1810 × 2000 | 3500 | 51 | 60 |
mixing tank discharge : conical bottom
by hot sell mixing tank, stainless steel mixing tank, pls contact us directly.
