Help CenterFuel Gas Steam Boiler
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Natural Circulation
Usage:
Industrial
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Disel Steam Generator Steam Boiler for Retort Sterilizer and Heating TanksUS$ 3,000 - 9,000MOQ: 1 Set -
Disel Heating Steam Generator Steam Boiler for Retort Sterilizer and Heating TanksUS$ 3,000 - 9,000MOQ: 1 Set
-
Carbon Steel Sterilizer Retort Cheap Sterilizer Retort for Glass JarUS$ 5,000 - 15,000MOQ: 1 Set
-
Retort for Glass Bottle SterilizerUS$ 5,000 - 15,000MOQ: 1 Set
-
Small Scale Sterilizer for Glass JarUS$ 4,500 - 9,800MOQ: 1 Set
Condition
New
Type
Natural Circulation
Usage
Industrial
Structure
Water Tube
Pressure
High Pressure
Style
Horizontal
Fuel
Other, Light oil,natural gas,heavy oil,liquefied preeoleum gas,city gas
Place of Origin
Zhejiang, China
Brand Name
Yongxing
Model Number
WNS1-1.0-Y(Q)
Output
Steam
After-sales Service Provided
Engineers available to service machinery overseas
Features:
1. Reliable three-pass and fully wet back structure.
2. Lateral-cut tube technology: increase heat efficiency.
3. Big combustion room design: increase radiated area, decrease emission of NOx, and reduce boiler cubage.
4. Big flue gas tube: reduce the resistance of smoke flow and consumption of electricity.
5. Intelligent control system: PLC and 5.7 touch panel, multi-level protections.
6. Fiberglass heat preservation: low surface temperature and heat loss.
7. Corrugated hearth: more safety and increase heat convection.
8. Multi-level sealing for flue gas chamber: no flue gas leakage.
9. Each boiler is subject to strict inspection and testing before delivery, including hydraulic pressure testing and X ray inspection.
10. Selecting the most suitable burner to match the boiler so as to guarantee safety and reach rated output.
11. Main components, such as burners, pumps, water level meters, valves are limited to renowned brands.
12. Stainless steel plate protective cladding for surface: fine appearance and effective protection.
13. A economizer is optional and possible to save 10% fuel and decrease noise 20dB.
14. Applicable fuels: gas, oil, dual fuel.
1. Reliable three-pass and fully wet back structure.
2. Lateral-cut tube technology: increase heat efficiency.
3. Big combustion room design: increase radiated area, decrease emission of NOx, and reduce boiler cubage.
4. Big flue gas tube: reduce the resistance of smoke flow and consumption of electricity.
5. Intelligent control system: PLC and 5.7 touch panel, multi-level protections.
6. Fiberglass heat preservation: low surface temperature and heat loss.
7. Corrugated hearth: more safety and increase heat convection.
8. Multi-level sealing for flue gas chamber: no flue gas leakage.
9. Each boiler is subject to strict inspection and testing before delivery, including hydraulic pressure testing and X ray inspection.
10. Selecting the most suitable burner to match the boiler so as to guarantee safety and reach rated output.
11. Main components, such as burners, pumps, water level meters, valves are limited to renowned brands.
12. Stainless steel plate protective cladding for surface: fine appearance and effective protection.
13. A economizer is optional and possible to save 10% fuel and decrease noise 20dB.
14. Applicable fuels: gas, oil, dual fuel.
15. Amended dimensions for export containerization to save shipping cost.
| The main standard of fuel gas boiler | |
| Model | WNS1-1.0-Y(Q) |
| Rated evaporation (t/h) | 1 |
| Rated steam pressure(Mpa) | 1 |
| Rated steam temperature(°C) | 184 |
| Water supply temperature(°C) | 20 |
| Heated area(m2) | 28 |
| Design efficiency | 83 |
| Design fuel | Light oil,natural gas,heavy oil,liquefied preeoleum gas,city gas |
| Ontology water volume(m3) | 2.21 |
| Dimension (L*W*H)(mm) | 3050*1624*1843 |
| Boiler transportation weight(Kg) | 2675 |
