Steam Heating Sterilzer Autoclave for Glass Jar

Name: Steam Heating Sterilzer Autoclave for Glass Jar
Brand: WANYUAN
SKU: 141367202
Availability: InStock

US$ 3,500 - 8,500 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Zhejiang, China

Brand Name:

WANYUAN

Wenzhou Longwan Wan Yuan Food Machinery Factory

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Zhejiang, China

Brand Name WANYUAN

Model Number 500L--20000L

Usage Canned Food

Type Autoclave

Warranty 1 Year

After-sales Service Provided Engineers available to service machinery overseas

steam retort autoclave

steam heating sterilzer autoclave for glass jar

food autoclave

meat sterilizing retort / canning retorts / cooking retort

Product Description of retort sterilizer
Product Description of retort sterilizer				Diameter of steriliztion kettle(MM)	DN1100	DN1300	DN1500
Mumber of basket(crate)	4	4	4
Maximum working pressure(MPA)	0.35	0.35	0.35
Maximum working temperature()	137	137	137
Operating velocity(R/MIN)	3-8 OR 6-12	3-8 OR 6-12	3-8 OR 6-12
Volume(M3)	0.7	1.3	2.1
Heating steam pressure(MPA)	0.6	0.6	0.6
Cyclic consumption of heating steam(KG)	300	400	600
Flow of heating steam(KG/H)	1000	1500	2500
Cooling water pressure(MPA)	0.35	0.35	0.35
Cyclic consumption of cooling water(M3)	5	7	10
Flow of cooling water(M3/H)	60	90	120
Compressed aie consumption(M3/MIN)	0.7	0.9	1.1
Electrical capacity(KG)	12-8	15-26	20-30
external Dimension LWH	580019003600	580021004000	580022004400

autoclave retort sterilizer for glass bottles pouch

Diameter of steriliztion kettle(MM)	DN1200	DN1300	DN1500
Mumber of basket(crate)	4	4	4
Maximum working pressure(MPA)	0.35	0.35	0.35
Maximum working temperature()	137	137	137
Operating velocity(R/MIN)	3-8 OR 6-12	3-8 OR 6-12	3-8 OR 6-12
Volume(M3)	0.7	1.3	2.1
Heating steam pressure(MPA)	0.6	0.6	0.6
Cyclic consumption of heating steam(KG)	300	300	300
Flow of heating steam(KG/H)	1000	1500	2500
Cooling water pressure(MPA)	0.35	0.35	0.35
Cyclic consumption of cooling water(M3)	5	7	10
Flow of cooling water(M3/H)	60	90	120
Compressed aie consumption(M3/MIN)	0.7	0.9	1.1
Electrical capacity(KG)	12-18	15-26	20-30
external Dimension LWH	580019003600	580021004000	580022004400
