hot sale water spray sterilizer retort
hot water spray retort . steam spray autoclave retort
Detailed Product Description
We are a specialist in the manufacture of retort sterilizer which has widely used
to completely sterilize the cooked food, processed beef, liquid food, and other
food after packaging.
We have three main types of retort sterilizers as follow:
1) Hot water spray retort sterilizer: the machine performs various types of high-pressure sterilization. Sterilization is achieved through the use of non-atomized
hot water droplets. The sterilized comprises a retort that is capable of receiving
multiple trays of materials, a pressurized air intake system for introducing
pressurized air into the retort, an exhaust system and multiple spray units capable
of spraying liquid such that at least one spray unit is disposed adjacent
to each tray of material. It is further defined to include a heat exchanger and
a pump for removing the liquid from the retort, passing it through the heat exchanger
and delivering the liquid to the spray units.
2) Shower spray rotary (static) retort sterilizer: WY shower spray rotary (static)
retort sterilizer is specially designed to sterilize foods in pouches and flexible
plastic containers such as pop cans, plastic bottles, glass bottles and heating
bags. Shower spray retort sterilizer sprays high pressured hot water to the packaging
food by nozzles located at the processing tank.
3) Hot water immersion retort sterilizer: WANYUANhot water imersion retorts are specially
designed to sterilize foods in pouches and flexible plastic containers.
It shall be ensured that all pouches are positioned in the water flow to give
much better uniformity of temperature distribution and heat transfer.
Retort Sterilizer(autoclave,retort)
-
Diameter of steriliztion kettle(MM) DN1100 DN1300 DN1500 Mumber of basket(crate) 4 4 4 Maximum working pressure(MPA) 0.35 0.35 0.35 Maximum working temperature() 137 137 137 Operating velocity(R/MIN) 3-8 OR 6-12 3-8 OR 6-12 3-8 OR 6-12 Volume(M3) 0.7 1.3 2.1 Heating steam pressure(MPA) 0.6 0.6 0.6 Cyclic consumption of heating steam(KG) 300 400 500 Flow of heating steam(KG/H) 1000 1500 2500 Cooling water pressure(MPA) 0.35 0.35 0.35 Cyclic consumption of cooling water(M3) 5 7 10 Flow of cooling water(M3/H) 60 90 120 Compressed aie consumption(M3/MIN) 0.7 0.9 1.1 Electrical capacity(KG) 12-18 15-26 20-30 external Dimension L*W*H 5800*1900*3600 5800*2100*4000 5800*2200*4400
