Perfumery Extract Co2 Supercritical Extraction plant
The supercriticalCO2 fluid extraction device was designed,first class extraction technique home and broad at present.
A.Brief Instroduction:
1.The extraction pressure can reach as high as 40Mpa. Extraction, separating and distillation temperature (indoor) can reach 80oC.The above mentioned data can be adjusted by the user.
2.Designed with one(1-24L) or several extraction pots (24-1000L) and separating pots integration.
3.Extraction and separating pots are of compact structure,easy to use,convenient to load and unload raw materials, with a strong antifatigue capability and safe in use.It can be made according to the customer's need. Large equipment are fitted with safety chain device.
4.Sample can be obtained on line during operation and the extracted fluid sample can be analyzed to determine the elements content. CO2 can be used calculatedly and its flow volume can be indicated by flow meter.
5.Temperature in different section is show by digital or meter control system, which is easy to operate and control. Pressure double safety-guard device are formed with safety valves and anti-explosion pieces. Computer control system can be provided if necessary.
6.The whole equipment is made of stainless steel, attractive and durable. It is the ideal equipment for food and pharmaceutical industry. The technique of making some relevant agent will also be attached.
B.Main Technical Parameters
Capacity(L) | 1 DF1 | 1 DF1 | 2 DF2 | 1+5 DF6 | 20 DF20 | 300 500 1000 3000 |
Pressure(MPa) | 40 | 40 | 40 | 40 | 35 | 35 |
Flow(L/h) | 10 | 10 | 30 | 60 | 200 | As per customer need |
Integration | 1E*2S 1D | 1E*2S1D&S | 2E *2S 1D | 2E *2S1D&S | 1E*2S1D | |
Capacity(L) | 25 | 50 | 50 | 100 | 100 | |
Pressure(MPa) | 35 | 35 | 35 | 35 | 25 | |
Flow(L/h) | 250 | 500 | 500 | 1000 | 1000 | |
Integration | 1E*2S | 2E*2S | 2E *2S 1D | 4E *2S | 4E*2S1D |
Remarks:
1.Ex for extraction pot;
2.S for separation pot;
3.D for distillation pipe;
4.&S for sampling on line.
Our Models of laboratary,pilot and industrial production type to your need.
Up to now, Supercritical fluid CO2 extraction achieve success in the follwing areas
essential oil
cosmetics function ingredient
We are welcome for your further inquiry!
Our company’s advantages over other companies:
Advanced Technology Co., Ltd Wenzhou is the a professional Stainless steel Mixing Equipment,Tank Pressure Vessels,Filters,Beer equipment and brewing technology supplier, who can professionally design, research and develop, and manufacture these equipment.
We can provide clients one-stop service from design, layout, to finished products. Its main business includes beer equipment, self brewing equipment, hotel beer equipment, draft beer dispenser, school laboratory equipment, etc. We mainly provide the capacity 500L/DF, 1000L/DF, 2000L/DF, 3000L/DF, 5000L/D,10000L/D,20000L/D etc.
Our staff of Sales and Technical Support is available to help you in selecting the right protection for your application as well as to provide you with Samples of our products for evaluation. At Advanced Tech., we are committed to providing the Highest level of customer service, Competitive pricing, Speedy delivery and a Comprehensive, cutting-edge product offering. Our ultimate goal is your satisfaction.
Our company’s quality certification:
We have got CE, PED, ISO9001 (2008) certificates. If necessary, we can offer electronic record’s certificates but the original document must be kept in the company.
Our company’s customer segmentation:
Our customer segmentation is mainly focused on the European,American developed countries such as the USA,Canada, Lati-America,the United Kingdom, Australia,
Saudi Arab and Asia etc. At present,we are looking for superior agents to create a brilliant future.
Shipment
Bulk cargo: standard wooden case which can avoid any clash during the sea or air transportation in case of causing damage to the equipment’s surface.
Container cargo: equipment will be bound firmly,won’t easily swing to the side, or up, or down.
