Stainless Steel Reaction tank
Introduction:
The reaction kettle is widely used for reaction, evaporation, conectration, synthesization, polymerization, mineratization, etc. in chemical industry, medecine, dye, pesticide, organic synthesis, petroleum,food additives, industry of national defense and scientific reserch. Our company is an enterprise specialized in designing and manufacturing reaction kettles, we can design and manufacture various types of reaction kettles for users.
Features:
1. According to different process, the reactor can be vacuum, hermetic seal, heating, or cooling.
It can configured with many kind of heating and cooling method, like electric heating, steam heating, hot oil heating, hot water heating, etc. for cooling can be cold water cooling,...
2. It can configured with various mixing method, like high speed disperser, high speed homogenizer paddle mixer, anchor mixer or high shear homogenizer, (kindly pls refer to below chart)
3. It can equip with frequency inverter to get more various speed, with reducer to get low speed.
4. inside and outside of reactor is finishing polished, surface isvery smoothly, easy to clean.
5. According to different requirement, the reactor can not platform or with legs on the floor
6. maintenance: there are manhole for big volume reactor, man can through manhole to maintenance or clean the reactor, if
small volume reactor, with handhole or with gland head, the head is removable.
7. material: ss304 or ss316L stainless steel, for acid or corrosive, inside wall can coating atiseptic material.
8. Volume: from 50 litre to 200000 litre
9. Voltage: 380v, 60hz, 3phase ( can customized )
Model selection reference of reaction kettle
Composition | Instructions |
Specification (L) | 50-50000L |
Design Pressure (Mpa) | Atmospheric Pressure or under pressure |
Material | Carbon steel, stainless steel, enamel, graphite |
Heating Forms | Electrical heating with medium in jacket, external half coil steam heating, external half conduction oil heating, hot water infrared heating etc. |
Cooling Forms | Refrigeration medium in the internal pipe jacket |
Blending Power | Model selection is made according to material viscosity, liquid-solid ratio, liquid specific gravity, solid specific gravity, solid granularity, rotation speed, paddle type, with or without baffle or internal coil. |
Stirring blade Forms | Anchor type, frame type, flat paddle type, pitched paddle type, ribbon type, turbo type, pusher type and multiple compound type |
Seal | Mechanical seal or stuff packing seal |
Inner Surface Treatment | Polished or no polished |
Discharge Valve | Flanged ball valve, open downward discharge valve and others |
Technological Pipe Hole | Manhole, sight glass, distillation mouth, imported materials, pressure gauge port, temperature, mouth, |
Pre-sale service:
1. Free of making offers, craft and technical guidance.
2. We can provide company’s qualification certification and the drawings.
3. We can also make customized products according to customer’s needs.
After-sale service:
1. We provide long-term after-sale service.
2. Meanwhile, you can call or e-mail to consult any relevant questions since we have a special line of after-sale service. Or you can communicate online and solve the problems.
Zhejiang Dafeng Light Industrial Industrial Machinery Co.,Ltd can provide our customers with high quality stainless steel Chemical Reactors with agitation to process product. These tanks with high pressure resist,high temperature resist for dye,paper,pharmaceutical,and other chemical process industries,standards meet to national pressure vessel manufacture requirements.
More than 20years history, has 8000m2 area, Located in Wenzhou city, Zhejiang Province, 24hours truck to Ningbo Port,welcome your Inquiry.
We take the customer's demand as a starting point, support the competitive price with best quality serve for customer.
Shipment
Bulk cargo: standard wooden case which can avoid any clash during the sea or air transportation in case of causing damage to the equipment’s surface.
Container cargo: equipment will be bound firmly,won’t easily swing to the side, or up, or down.
We can offer several payment methods which can ensure your capital’s security, such as the following:
L/C T/T D/A D/P
Western Union
MoneyGram
