Application
1) Reactor is the main chemical reaction of the typical production equipment, which is widely used in resins, adhesives, paint, cosmetics, pharmaceutical and other chemical production.
2) To break down or combined the materials through mixing, filling and cooling, to promote the reaction of polymerization.
3) The reactor consists of body, gears, mixing devices, heating devices, cooling devices, seal composition.
4) Corresponding auxiliary equipment: distillation column, condenser, water separator, collecting cans, filters ect.
2.Used in:
1). Unsaturated resin, alkyd resin, acrylic resin, polyester resin, curing agent and complete sets of production equipment.
2). Emulsion, white latex, water-based polyurethane, water-based glue sets of production equipment.
3). 107 rubber, silicone oil, anc other sets of production equipment, hot melt adhesive.
4). Complete sets of production equipment.
5). PU glue, adhesive, grafted gum syrup glue sets of production equipment.
6). Complete sets of raw rubber production equipment.
7). Waste silicone cracking, distillion, recycling sets of production equipment.
8). Dispersion paints, coatings, stirring and mixing equipment.
Steam heating reaction vessel
Specification | Nominal capacity(L) | CM (mm) | Jacket Size(mm) | Motor power (Kw) | Stirring Speed (rate/Min) |
300L | 200 | Φ800 | Φ900 | 2.2 |
50~80 |
500L | 500 | Φ900 | Φ1000 | 2.2 | |
1000L | 1000 | Φ1200 | Φ1300 | 3 | |
1500L | 1500 | Φ1200 | Φ1300 | 3 | |
2000L | 2000 | Φ1300 | Φ1400 | 4 | |
3000L | 3000 | Φ1500 | Φ1600 | 5.5 | |
5000L | 5000 | Φ1800 | Φ2000 | 7.5 | |
6000L | 6000 | Φ1800 | Φ1900 | 15 | |
10000L | 10000 | Φ2200 | Φ2400 | 18.5 |
85 |
16000L | 16000 | Φ2400 | Φ2600 | 22 |
Outside dish tubular reactor
Our company’s advantages over other companies:
Advanced Technology Co., Ltd Wenzhou is the a professional Stainless steel Mixing Equipment,Tank Pressure Vessels,Filters,Beer equipment and brewing technology supplier, who can professionally design, research and develop, and manufacture these equipment.
We can provide clients one-stop service from design, layout, to finished products. Its main business includes beer equipment, self brewing equipment, hotel beer equipment, draft beer dispenser, school laboratory equipment, etc. We mainly provide the capacity 500L/DF, 1000L/DF, 2000L/DF, 3000L/DF, 5000L/D,10000L/D,20000L/D etc.
Our staff of Sales and Technical Support is available to help you in selecting the right protection for your application as well as to provide you with Samples of our products for evaluation. At Advanced Tech., we are committed to providing the Highest level of customer service, Competitive pricing, Speedy delivery and a Comprehensive, cutting-edge product offering. Our ultimate goal is your satisfaction.
Our company’s quality certification:
We have got CE, PED, ISO9001 (2008) certificates. If necessary, we can offer electronic record’s certificates but the original document must be kept in the company.
Our company’s customer segmentation:
Our customer segmentation is mainly focused on the European,American developed countries such as the USA,Canada, Lati-America,the United Kingdom, Australia,
Saudi Arab and Asia etc. At present,we are looking for superior agents to create a brilliant future.
Shipment
Bulk cargo: standard wooden case which can avoid any clash during the sea or air transportation in case of causing damage to the equipment’s surface.
Container cargo: equipment will be bound firmly,won’t easily swing to the side, or up, or down.
