Stainless Steel Stirring Tank Mixing Tank for Food Beverage Chemical Cosmetic

Stainless steel Stirring Tank mixing tank for food beverage chemical cosmetic

 100-10000L stainless steel  mixing tank  we supply all types and sizes of tanks to various processing industries. Some of these processing industries include food, beverage, dairy, chemical, pharmaceutical, nutraceutical, fruit & vegetable, sauce and dressing, cosmetics, food protein, lotions, candy and many other processing industries.

We can offer all types and sizes of processing tanks, depending on your needs, such as steam jacketed, double motion agitated, triple motion agitated, scrape surface agitated, self contained, gas-fired, electrically heated, tilt-type, vacuum type, high shear agitated, single motion agitated, pressure, cooking, cooker/cooler and all other types.

Description

1.There are three styles: vertical single layer,double layers,and 3 layers structure.
2.The outside layer that keeps warm uses polyurethane foam or pearwool.
3.The pars that touch the medical liquid adopt the 316L material, the other parts 304 material
4.There are water entrance, circumfluence entrance.Sanitizing entrance,cleaning entrance and manhole for filling material, breathing entrance with an air breather, 0.22um, on the top. And on the bottom there are entrance for condensed water, entrance for distilled water, entrance for dirty water, entrance for measuring the liquid level, and entrance for measuring the temperature. The operation of Controlling ark and the meter is showing the temperature of distilled water, liquid level realize the auto-controlling of constant temperature and alarming when above the upper limit and below the lower limit.

Specification：

  1 the heat preservation material of the vessel is high-temperate resistant and anti-aging polyurethane blister or pearl cotton.
 2 the interface adopts internationally general ISO rapid installation chuck type product.the internal bladder adopts imported stainless steel SUS316L or SUS 304. the internal surface adopts mirror polishing unit RA less than 0.28um,and the external surface adopts polishing, mirror polishing,sandblasting ,cold rolling original color matte treatment.All of the above conform to GMP standard.
  3 the selling of the blender adopts imported sanitary mechanical seal device,and the blending rotation speed is optional
  4 the pipe mouth is provided with liquid meter vent (static pressure type,capacitance type,non-contact type ,ultrasonic type or glass tube type),air spiracle,thermometer(digital indication type or dial plate type) CIP cleaning vent,sight glass,anti-explosion view lamp(integrated sight glass and view type),SIP sterilization vent, liquid inlet and outlet ,sanitary manhole and etc.
 5 the volume varies within the range of 100L-20000L ,or design and manufacturing can be made according to actual requirements of customers
  6 the GMP certification document attached in the machine are avalible(including material report,certification of outsourcing parts,verification form and etc.
