ANSI / ASME / DIN / BS / JIS B16.5 Carbon Steel/Stainless Steel Flange Manufacture

Advanced Tech. Co., Ltd. Wenzhou

US$ 90 - 500 MOQ: 1 Piece

Key Specifications

Material:

Other, Stainless Steel, Stainless steel 304/316/316L

Technics:

Casting

Type:

Flange

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Material Other, Stainless Steel, Stainless steel 304/316/316L

Technics Casting

Type Flange

Place of Origin Zhejiang, China

Model Number FLANGE

Brand Name DF

Connection Other, Tri-Clamp

Shape Reducing

Head Code Hexagon

Product Description

Product class:Sanitary Fluid pipe Fittings Series
Sanitary flange

Material quality:SUS304.SUS316L

Type:	Stainless Steel Flange
Sizes:	Size 1/2”—24”( DN 15-DN 600);
Grade:	304/304L(1.4301/1.4306/1.4307);316/316L/316Ti(1.4401/1.4404/1.4571);321(1.4541);
Standards:	AISI B 16.5,JIS B2220,ASME B16.47,DIN,EN,BS Standards
Process:	Forged Flanges
Packing:	By wooden cases or as customer requests
Others:	Mill Test Certificate As EN 10204.3-1

ANSI/ASME/DIN/BS/JIS B16.5 Carbon Steel/Stainless Steel Flange Manufacture:

1.DN15-6000mm

2.ANSI,JIS,DIN,ISO standard
3.lots stock forged carbon steel flange

Introduction of ANSI/ASME/DIN/BS/JIS B16.5 Carbon Steel/Stainless Steel Flange Manufacture:

Product
Welding neck	Slip on	Blind
Long welding neck	Lap joint	Socket weld
Threaded	Orifice	Spectacle Blind
Spacer and Blank	Ring Joint Flange	Flange outlet
Weld outlet	Socket outlet	Forged ring
Square flange	Girth flange	Forgings
API flange	Special Nozzles	Forged rings
Customer's desigh item	CNC production item
Standards
ANSI B16.5	1/2"-24"
ANSI B16.47 Series "A"(MSS SP44)	26"-60"
ANSI B16.47 Series "B"(API 605)	26"-60"
AWWA C207	4"-120"
BS 3293	26"-48"
DIN EN1092-1	1/2"-160"
API 590	1/2"-24"
JIS/KS	1/2"-60"
Non-standard(customer's design)	Max. OD 5.000mm X 500mm thk Max.25Tonne
Material
Carbon steel(A36,A105, A266 CL2/CL4,ST37.2, C22.8,S235JR,S275JR,S355JR)
Plate material(A515 Gr60/70,A516 Gr60/70,A285GrA B C,A240 304,A240 316)
Low Temp Carbon steel (A350 LF2 CL1/CL2/LF3)
High Yield Carbon steel(A694 F42/F52/F60/F62/F65/F70)
Stainless steel(A182 F304/L, F304H, F316/L,F317/L,F44)
Low alloy steel (A182 F1, F5,F9,F11 CL1/CL2/CL3, F12 CL1/CL2, F22 CL1/CL3, F91)
Duplex stainless steel (A182 F51/UNS 31803, F52/UNS32950, F53/UNS 32750)
