15bbl Stainless Steel Double Jacketed Beer Fermenter

15bbl stainless steel double jacketed beer fermenter

CE 2000 and ISO 9001 certificate.



4 stainless steel legs with leveling footpads



Interior shell: 304 or 316L stainless steel, thickness 3mm



Exterior shell: 304 stainless steel, thickness 2mm



Interior and exterior finish bright polish to 0.4~0.8, hygiene surface



60 degree cone bottom, other angles can be specified during the design process



Combined drain extensions and beer port in cone are standard



Top manway or side manway door



Dual zone in sidewall and cone dimple cooling jacket with glycol inlet and outlet



Polyurethane insulation thickness 50mm for cooling jacket on side and bottom



Fully welded exterior shell



Non welding CIP arm and rotating 360 degree reach spray ball



Solenoid relief valve, pressure relief valve (safe valve) are standard



Pressure gauge



Temperature sensor well



Sanitary sample valve and port



All clamps and gaskets to attach all accessories



Tank complete with piping, fittings, sanitary valves and all parts.

TECHNICAL SPECIFICATION

Inner surface	S.S.304,WELL POLISHED,polishing precision≤0.4µm,THK:2-4mm
Outside surface	S.S.304,frosted or mirror,THK:1.5-3mm
Top shape	Seal head or conical head
Conical degree	60-90°c
Manhole location	Side upward/side/flanged
Insulation	Material:PU,THK:50-100mm
Cooling jackets	DIMPLED cooling jackets at bottom and side wall.
Spray ball	Located in the center of inside of the tank
Pressure	0.2MPa
Thermometer	Bi-metal thermometer
Legs	3/4 round legs,can designed to be adjustable
The ratio of working volume to gross volume	4/5
Operational method	Automatic or manual
Technology processing	Argon-arc welding,well weld in double sides.



Product Display







Pre-sale service:

1. Free of making offers, craft and technical guidance.

2. We can provide company’s qualification certification and the drawings.

3. We can also make customized products according to customer’s needs.

 After-sale service:

1. We provide long-term after-sale service.

2. Meanwhile, you can call or e-mail to consult any relevant questions since we have a special line of after-sale service. Or you can communicate online and solve the problems.

     Advanced Technology Co., Ltd Wenzhou is the a professional beer equipment and brewing technology supplier, who can professionally design, research and develop, and manufacture the brewing equipment.  we can provide clients one-stop service from design, layout, to finished products. Its main business includes beer equipment, self brewing equipment, hotel beer equipment, draft beer dispenser, school laboratory equipment, etc. We mainly provide the capacity 500L/DF, 1000L/DF, 2000L/DF, 3000L/DF, 5000L/D etc.

      Our staff of sales and technical support is available to help you in selecting the right protection for your application as well as to provide you with samples of our products for evaluation. At Advanced Tech., we are committed to providing the highest level of customer service, competitive pricing, speedy delivery and a comprehensive, cutting-edge product offering. Our ultimate goal is your satisfaction.

 Shipment

Bulk cargo: standard wooden case which can avoid any clash during the sea or air transportation in case of causing damage to the equipment’s surface.

Container cargo: equipment will be bound firmly,won’t easily swing to the side, or up, or down.
