Sell Triplicate (Multiple-effect) Energy Saving Vacuum Concentrating Equipment

Sell Triplicate (Multiple-effect) Energy Saving Vacuum Concentrating Equipment photo-1
Sell Triplicate (Multiple-effect) Energy Saving Vacuum Concentrating Equipment photo-2
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
DF
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Zhejiang, China
Brand Name DF
Model Number SJN
Processing Types Other, herbal and plant
Voltage customized
Power(W) customized
Weight customized
Dimension(L*W*H) customized
Certification ISO9001
Warranty 2 Years
After-sales Service Provided Engineers available to service machinery overseas
Use: This equipment is suitable for evaporation and concentration liquid material and  recovering the organic solvent and cream in pharmaceutical, foodstuff and chemical industry etc.

Summarize
1.The equipment combines the external circulation heating system with the way of vacuum concentration together in order to enhence the evaporation speed and the concentration proportion can get above 1.2.
2.The liquid materia is concentration in a vacuum condition and the finished material is without pollution and the organic solvent.lso can be recovered.
3.With the effection of triplicate-efficient coinstantaneous evaporation,the steam can be used sufficiently, so it can save the energy consumption.Compare with the single-efficient concnetrator , the energy can be saved more than more 60%.
4.The top of heater is with opening device so it is easy to clean.The equipment is also with automacit drainage system in order to lighten the labor intensity .
5.The equipment configure with PLC control system in order to controll the temperatue ,pressure,feedig and uncharging the material automatically.

Main technical parameter

model

SJN3-500

SJN3-1000

SJN3-1500

SJN3-2000

SJN3-3000

evaporate capacity (kg/h)

500

1000

1500

2000

3000

steam cost(kg/h)

220

400

620

800

1240

steam pressure(Mpa)

less than 0.25

temperature(°C)

one effect85-95 two effects70-80three effects55-65

vacuum degree(Mpa)

one effect-0.02~-0.04two effects-0.05~-0.06three effects-0.08~-0.09

water cost(t/h)

9

18

27

36

60

dimension(m)

5.3*1*3.4

7*1.5*4.

7.5*1.5*4

7.9*1.8*4

8.5*2*4.3

The above parameter  for reference,which the drawing parameter is for standard.

Sell Triplicate (Multiple-effect) Energy Saving vacuum Concentrating equipment

Company Information

Our company’s advantages over other companies:



      Advanced Technology Co., Ltd Wenzhou is the a professional Stainless steel Mixing Equipment,Tank Pressure Vessels,Filters,Beer equipment and brewing technology supplier, who can professionally design, research and develop, and manufacture these equipment.

We can provide clients one-stop service from design, layout, to finished products. Its main business includes beer equipment, self brewing equipment, hotel beer equipment, draft beer dispenser, school laboratory equipment, etc. We mainly provide the capacity 500L/DF, 1000L/DF, 2000L/DF, 3000L/DF, 5000L/D,10000L/D,20000L/D etc.

Our staff of Sales and Technical Support is available to help you in selecting the right protection for your application as well as to provide you with Samples of our products for evaluation. At Advanced Tech., we are committed to providing the Highest level of customer service, Competitive pricing, Speedy delivery and a Comprehensive, cutting-edge product offering. Our ultimate goal is your satisfaction.

Our Services

Our company’s quality certification:



We have got CE, PED, ISO9001 (2008) certificates. If necessary, we can offer electronic record’s certificates but the original document must be kept in the company.

Our company’s customer segmentation:

Our customer segmentation is mainly focused on the European,American developed countries such as the USA,Canada, Lati-America,the United Kingdom, Australia,

Saudi Arab and Asia etc. At present,we are looking for superior agents to create a brilliant future.

Packaging & Shipping

Shipment



Bulk cargo: standard wooden case which can avoid any clash during the sea or air transportation in case of causing damage to the equipment’s surface.

Container cargo: equipment will be bound firmly,won’t easily swing to the side, or up, or down.
