Specifications
Fiberglass fabric--7628:1,flat and no fuzz
2,excellent electric insulation
3,plain weave,twill weave
Specifications
Fiberglass fabric--7628:
1,flat and no fuzz
2,excellent electric insulation
3,plain weave,twill weave
Fiberglass fabric--7628:
is a kind of alkali-free glass fiber fabrics produced by utilizing abroad advanced technology and equipment. By means of a surface treatment it has excellent electro-insulation property and workability. It is used mainly in printed circuit boards, and is also used as base materials for computers and home electro-devices.
7628, 0.18mm 200g/m2, Plain Fiberglass fabric
Characteristic
7628
Weave
Plain
Yarn
(text)Warp
WeftEC9 33 2×1
EC9 33 2×1ECG 150 2/1
ECG 150 2/1Width
101.6±2cm
127±2cm
152.4±2.54cm40±0.75inch
50±0.75inch
60±1 inchThickness
0.20±0.02mm
0.0079±0.0007inch
Weight
200±20g/m²
5.8±0.5oz/yd²
Thread
countWarp
Weft17±1.7/cm
12±1.2/cm45.7±4.5/inch
33±3.3/inchTensile
strength
minWarp
Weft2025N/5cm
1620N/5cm225 ibs/inch
180 ibs/inchL.O.I%
1.0%
Service Temperature
