Automatic Vacuum Packaging Machine
Machine introduction:
MP1000 is specialized in packing products into vacuum status and brick shapes, various kinds of powder or granules are available, such as coffee, yeast, tea leaves etc. It’s best to work with vertical form fill and seal machines to complete the automatic bagging line, Which consisting of screw loading conveyor with vibratory hopper feeder, auger filler dosing system, automatic bag making machine with date printing unit, and the vacuum brick maker. Packed bag keep high quality in sealing, long time in reserving, smart in outlook.Advanced in vibration, pressing, reforming, vacuuming, sealing, cutting, smoothing and conveying such chief processing step, take result in getting nice bag shape and appropriate vacuum degree.
Advantage:
MP1000 Vacuum &bag bag reshape system |
|
Machine working Steps:
Get bag from VFZ series: vertical form fill & seal machine - Vibrate the bag - Form the bag shape - Vacuum & seal bag - Output bag
Technical Specification:
Bag type |
Vacuum & Reseal Brick Bag |
|
Maximum Capacity |
up to 2 kilograms( have to change auger & tube according to different weighting range ) |
|
Minimum Capacity |
depend on product characteristics but nominally 5 grams |
|
Speed |
8-20(times/min) dependant on products characteristics and weighting range |
|
Hopper capacity |
50Litres |
|
Weighing accuracy |
±0.2% dependant on products characteristics |
|
Bag Length |
50 to 340mm (2.0 to 13.4in) |
|
Bag Width |
80 to 260mm (3.1 to 10.3in) |
|
Reel Film Width |
≤540mm (21.2in) |
|
Film thickness |
0.04-0.12mm (40-120mic.) |
|
Reel Outer Dia. |
400mm (15.7in) |
|
Reel Inner Dia. |
75mm (2.9in) |
|
Voltage |
AC220V/50Hz, 1phase or Per customer specification |
|
Power Consumption |
VFS5000F packaging machine |
3KW |
CJSL2000 Auger filler |
1.2kw |
|
GM1000 Vacuum &bag bag reshape system |
5.5KW |
|
Compressed Air Requirement |
0.6 MPa0.36 M3min |
|
Machine Size |
VFS5000F packaging machine |
L1650 x W1140 x H1650; (in):L65.1 X W44.9 X H64.9 |
CJSL2000 Auger filler |
L1000 X W950 x H2200mm; (in):L39.4 X W37.4 X H86.6 |
|
GM1000 Vacuum &bag bag reshape system |
L3125 mm W 660 mm H 1050 mm; L 123.03 in W 25.98 in H 41.34 in |
|
Machine Weight |
VFS5000F packaging machine |
800kg |
CJSL2000 Auger filler |
250kg |
|
GM1000 Vacuum &bag bag reshape system |
600kg |
|
Product show
