Equipment for the production of mineral water
Brand;
PLC; MITSUBISHI
Frequency transformer: MITSUBISHI
Model |
CGF12/12/6 |
CGF18/18/6 |
CGF24/24/8 |
CGF32/32/12 |
CGF40/40/12 |
CGF50/50/12 |
|
Production capacity:500ml (B/h) |
4000 |
6000 |
12000 |
15000 |
20000 |
24000 |
|
Suitable bottle standard(mm) |
150-300 |
150-340 |
150-340 |
150-340 |
150-340 |
150-340 |
|
Suitable cap standard(mm) |
φ50-φ110 |
||||||
Filling pressure(Mpa) |
0.2-0.3 |
||||||
Installed power |
3.13 |
3.84 |
3.84 |
5.6 |
6.3 |
7.3 |
|
Filling temperature |
Room temperature |
Room temperature |
Room temperature |
Room temperature |
Room temperature |
Room temperature |
|
|
Overall size: L*W*H(mm) |
2400*1760*2350 |
2470*1970*2350 |
2865*2170*2350 |
3700*2570*2350 |
3800*2950*2400 |
4500*3400*2400 |
|
Total weight(kg) |
2500 |
3000 |
4000 |
5000 |
6000 |
7000 |
|
Equipment for the production of mineral water
The Mineral water production equipment is used in production of non-soda drink of mineral and pure water packed in PET bottles. Washing, filling and capping are integrated in one machine.
The most advantaged technology from Japan and Germany is employed in the design. The gravity fixed liquid surface filling is fast, the amount of liquid is accurately controlled and the dropping and leakage are avoided.
Spring cramps are used in the bottle washing process. The empty bottles can be turned over 180º along the conveying rail. There are two times of internal and external washing. The efficiency of bottle washing is high.
The magnetic torque is used for screw capping. The power of screw capping can be adjusted without steps. The power of the screw capping can also be fixed, and the caps will not be damaged, the capping is reliable.
Mineral water filling machine,water filling machinery
The Mineral water production equipment is controlled by PLC with touch-screen as the human-machine interface. The amount of the drinks in the storage tank can be controlled automatically. The filling and capping will stopped automatically when there is no bottle. when bottles are cramped wrongly . the machine can be stopped automatically.
Equipment for the production of mineral water
We use high quality stainless steel and have more than 10 years experience in this filed. I belive our excellent quality and good price must satisfy you.
Equipment for the production of mineral water
Please contact me soon as you have any detail questions.
