Full Automatic Washing Filling and Sealing Mineral Water Equipment
US$ 51,200 - 52,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Mineral Water
Packaging Type:
Bottles
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Mineral Water Filling MachineUS$ 69,800 - 70,000MOQ: 1 Set -
Pure Water Filling and Sealing MachineUS$ 20,000 - 21,000MOQ: 1 Set
-
Drinking Water Filling MachineUS$ 20,000 - 21,000MOQ: 1 Set
-
Bottle Water Making MachineUS$ 20,000 - 21,000MOQ: 1 Set
-
Bottling Filling Machine for WaterUS$ 50,000 - 51,200MOQ: 1 Set
Condition
New
Application
Other, Mineral Water
Packaging Type
Bottles
Packaging Material
Plastic
Automatic Grade
Automatic
Driven Type
Electric
Voltage
380V
Power
9.18KW
Place of Origin
Jiangsu, China
Brand Name
Mars
Model Number
CGF32/32/10
Dimension(L*W*H)
3600*2800*3150mm
Weight
5000kg
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
Full automatic washing,filling and sealing mineral water & pure water bottling equipment
Product Description:
The machine is mainly used in the beverage filling operations. The three functions of bottle wash, fill and seal are composed in one body of the machine. The whole process is automatic. The machine is used in filling juices, mineral water and purified water in bottles made of polyester and plastics. The Machine can also be used in hot filling if being installed with temperature controlling device. The handle of the machine can be freely and conveniently Turned to adjust the machine to fill various types of bottles. The filling operation is faster and more stable because the micro pressure filling Operation of the new type is adopted. There the output and benefit of the machine is higher than the machines of the same specifications. The advanced OMRON programmed controller (PLC) is adopted to control the machine to run automatically while a transducer is used in the bottle -entering chains to Adjust speeds and coordinated with the transducer of the main machine to make the operations of moving bottle forward steadily and reliably. It is Convenient to operate with higher automation because every part of the machine is inspected to run with photo electricity, On the bases, the filling Parts of the machine can be changed into filling methods of lower vacuum. The filling category of lower vacuum (Z type machine) is applicable in glass Bottles, filling alcohol, soy and such like materials. The aluminum theft proof cap and plastic cap can be adopted. The machine is an idea-preferred equipment for beverage makers
Technique parameter:
| Model: | CGF18-18-6 | CGF24-24-8 | CGF32-32-12 | CGF40-40-12 | ||
| Capacity :500ml | 5000 | 8000 | 12000 | 16000 | ||
| Bottle shape: | roud or square | |||||
| PET bottle: (mm) | (Bottle Diameter):φ50-.φ110mm (Height):150-340mm | |||||
| Cap: | PE srew cap | |||||
| Filling precision: | ≤±5mm | |||||
| Filling pressure:(Mpa) | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 | ||
| Rinsing pressure:(Mpa) | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 | ||
| Filling volume :(L) | 3.5 | 4 | 6 | 8 | ||
| Overall size:(mm) |
2450*1800 *2350 |
2780*2200 *2350 |
3600*2650 *2350 |
3800*2950 *2400 |
||
| Weight: (kg) | 3500 | 4500 | 5500 | 6500 | ||
Product photo
