Still Water Filling Machine

Still Water Filling Machine photo-1
US$ 23,000 - 24,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Mineral water
Packaging Type:
Bottles
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Other, Mineral water
Packaging Type Bottles
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Electric
Voltage 380V
Power 6.57Kw
Place of Origin Jiangsu, China
Brand Name Mars
Model Number CGF24-24-8
Dimension(L*W*H) 2750*2180*2200mm
Weight 5500Kg
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

This series of still water filling machine are mainly used for washing, filling, capping Non-aerated carbon dioxide drink such as mineral water, pure water, non-gas wine drink and so on, The machine design is shorten the time for the drink material contact with outside. Increased sanitation condition and economy.

Character:

It adopts hanging type conveying-bottle structure to make changing bottle model more convenient faster and more easy. The main machine adopts advanced PLC control technology. The key electric elements adopt international famous products.

Technical parameter:

Model: CGF24-24-8

Production capacity: 8,000B/H(500ml)

Filling precision: ≤±5mm (liquid level)

Filling pressure: <0.4Mpa

Polyester bottle specification: bottle diameter:φ50-φ120mm

Bottle height: 150-320mm

Suitable cap type: plastic screw cap

Water pressure of washing bottle: 0.18-0.25Mpa

Water consumption for washing bottle: 2500Kg/h

Spraying position: 6

Dripping bottle position: 3.5

Gas source pressure: 0.4Mpa

Gas consumption: 0.4m3/Min

Total power: 6.57Kw

Overall dimension: 2750×2180×2200mm



If you have any inquiries please let me know, and we sincerely welcome you to visit our factory.
