SUS304 pure water machine production line
Introduction:
This kind of machine in used in the production of non-carbonated drink,such as mineral water and pure water. Washing, filling and capping are integrate into one machine.And this machine is using common pressure technology.
Water Machinery Production Line Characteristics:
1. Air Conveyor connects with bottle-in starwheels. Bottle neck holding transferred.
2. Clamp transferring technology varied bottle types
3. With ring type pressure bearing hydraulic cylinder
4. With high filling speed and exact liquid level.
5. Excellent Stainless Steel. Electric Components are of world known brand. All achieve national sanitary standard.
6.The bottle-out starwheel is of screwdown shape.No need to adjust transfeering chain's height to different bottles.
Water Machinery Production Line Technical standard:
NO. |
Model |
CGF18-18-6 |
1 |
Capacity |
6000 B /H |
2 |
Filling Accuracy |
≤±5MM |
3 |
Filling Pressure |
<0.4 |
4 |
PET bottle size (mm) |
Bottle dimension Φ40-Φ110 bottle height Φ130-320 |
5 |
Cap-shaped |
Plastic screw cap |
6 |
washing bottle of water pressure |
0.18Mpa |
7 |
Volume of washing bottle |
800kg/h |
8 |
spraying position |
6 |
9 |
dripping bottle position |
5 |
10 |
Consumption |
0.3m³/min |
11 |
Total power |
5.03kw |
12 |
Total weight |
3000kg |
13 |
dimensions |
2600×1900×2500mm |
