Heat Shrink Packaging Machine

Name: Heat Shrink Packaging Machine
Brand: Mars
SKU: 141356086
Availability: InStock

US$ 1,000 - 11,000 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

Beverage

Packaging Type:

Bottles

Zhangjiagang Mars Packing Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Beverage

Packaging Type Bottles

Packaging Material Plastic, Glass

Automatic Grade Automatic

Driven Type Electric

Voltage 380v

Power 20 kw

Place of Origin Jiangsu, China

Brand Name Mars

Model Number SP-10

Dimension(L*W*H) L6500mm*3200mm*2100mm

Weight 1200Kg

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Heat Shrink Packaging Machine

Shrink wrapping machine specially designed for the full automatic packaging production line of beer, beverage,purewater,fruit juice,dairy products,etc.
With full automatic functions of bottle transfer and arrange, membrane packing ,sealing and cut,shrinkage,cooling and shaping,etc.
Using advanced constant temperature membrane heat binding technology in the world with clear and secure seal.
The quick seal cooling structure guarantee that the seal has a higher strength even if under high speed production condition.
Adopt with PLC automatic program circulation control with stable and reliable performance.
The original imported guide bar cylinder guarantee correct op[eration and durable.
The inductive switch controls the membrane transfer system to reliably adjust and control the membrane transfer length with less loss.
All the transfer system is controlled by frequency changing devices With stable and smooth transfer speed.
Unique thermal passage with 2 sets of centrifugal thermal air circulation system that has an equal heat distribution with beautiful and secure shrinkage effect.
3 layers of heat insulation treatment with good insulating property,quick temperature rise and energy saving.
The enhanced cooling shaping passage can quickly turn the packaging membrane into high strength status that is conveniently stored and transported.

It is easy to change the packaging combination and bottle type to integrate the multi-function into one machine.

SPECIFICATION:

Dimension for the whole unit:	L6500mm×W3200mm×H2100mm
Thermal shrinkage passage dimension:	L1800mm×W650mm×H450mm
Max.package dimension:	L600mm×W400mm×H350mm
Transfer belt dimension:	304 mm
Packaging speed:	10-12Pcs/min
Operating power supply/power:	380v 33 kw
Sealing and cut time/temperature:	0.5-1.5s140^oC-160^oC
Operating air pressure:	0.6-0.8Mpa
Air consumption:	0.5m³/minute
