Cup Filler Sealer

Cup Filler Sealer

Application:

  Automatic yoghurt cup filling sealing machine for yoghurt milk all kind of dairy products. Yoghurt c

Functions:
1) automatic cup dropping

2)automatic filling

3) automatic absorb paper film

4) automaticUV extinction strain

5) automatic two side sealing

Cup Filler Sealer Features:

1)Japan Omron programmable logic controller

2)CIP automatic cleaning barrel

3)Taiwan Pneumatic control  components

4) Intelligent Digital Display Temperature Control system

sealing with high strength,good sealing and low failure rate, special chnges can be made for specific

Cup Filler Sealer Technical Parameter
production capacity:  200-5500cups/hour (special order optional)
filling range:               50ml--250ml (special order optional)
heating power:           5KW
gas consume:             0.8 M3/min
voltage:                      220V 50HZ
size:                           3000mm*800mm*1750mm
weight:                       900kg
