Pet Bottle Filling Machine
This DCGF bottle filling machine is a 3-in-1 washing, filling and capping monoblock. It is mainly used for filling carbonated soft drink(CSD) into PET bottles, such as cola, gas drink, carbonated drink, oxygen water, soda water, etc. It carries out washing bottle, isobaric filling and capping in one machine. The main machine adopts advanced PLC control and touch screen, no bottle no filling, no bottle no capping system. Production capacity is 8,000BPH (optioned from 2,000BPH to 36,000BPH) based on 500ml PET bottle.
BOTTLE FILLING MACHINE FEATURES
- The air conveyor is directly connected with bottle inlet starwheel. The bottles are transferred by neck holding.
- High speed filling line is of clamping transferring technology. Bottle shapes are more varied, and the working table inside the machine is more laconic.
- By 3-in-1 monoblock, the bottle goes through rinsing, filling and capping with little abrasion, and the transferring is stable, bottle changing is easier.
- Specially designed stainless steel bottle clamps don't contact the thread parts of the bottle neck, avoiding the second contamination.
- The high speed line is of ring type pressure bearing hydraulic cylinder.
- High speed and large flow filling valve assures the high filling speed and exact fluid level.
- Liquid contact parts are all of excellent stainless steel or food level rubber. The electrical parts and pneumatic components are of international brand and achieve the national food sanitary standard. Such as PLC from OMRON or SIEMENS, motors from SEW, pneumatic components from SMC or AIRTAC, etc.
- The bottle outlet starwheel is of screwdown shape. When bottle size is changed, there is no need to
- adjust the transferring chain’s height.
BOTTLE FILLING MACHINE TECHNICAL PARAMETER
Model No. |
DCGF14-12-4 |
DCGF16-16-5 |
DCGF18-18-6 |
DCGF24-24-8 |
Rinsing heads |
14 |
16 |
18 |
24 |
Filling heads |
12 |
16 |
18 |
24 |
Capping heads |
4 |
5 |
6 |
8 |
Production capacity |
2000BPH |
4000BPH |
6000BPH |
1000BPH |
| ||||
Model No. |
DCGF32-32-8 |
DCGF40-40-10 |
DCGF50-50-12 |
DCGF60-60-15 |
Rinsing heads |
32 |
40 |
50 |
60 |
Filling heads |
32 |
40 |
50 |
60 |
Capping heads |
8 |
10 |
12 |
15 |
Production capacity |
14000BPH |
18000BPH |
20000BPH |
24000BPH |
