Help Center60 Heads Monoblock Bottle Filling Machine
Related Products
60 Heads Monoblock Bottle Filling Machine- Complete Mineral Water Bottling Machine,Pure Water Production Line
(1) This bottling machine is mainly used for washing, filling and capping PET bottle which can fill non- carbonated drinks such as mineral water, pure water, wine and so on.
(2) Bottle washing, filling and capping are achieved in one machine.
(3) The contact time is shorten between material and the outside. And improved the health conditions, production capacity and economic benefits.
(4) CGF series bottling machine adopts hanging type conveying-bottle structure to make changing bottle mold more convenient, faster and more laborsaving.
(5) The main machine adopts advanced PLC control technology. The key electric elements adopt Mitsubishi, Omron, Siemens, etc international famous products.
Complete mineral water bottling machine,pure water production line
Water Bottle Filling Machine Parameters
Type |
CGF14/12/4 |
CGF16/16/5 |
CGF18/18/6 |
CGF24/24/8 |
CGF32/32/10 |
CGF40/40/12 |
CGF50/50/12 | CGF60/60/15 |
Washing heads |
14 |
16 |
18 |
24 |
32 |
40 |
50 | 60 |
Filling heads |
12 |
16 |
18 |
24 |
32 |
40 |
50 | 60 |
Capping haads |
4 |
5 |
6 |
8 |
10 |
12 |
12 | 15 |
|
Capacity Base on 500ml |
4000bph |
6000bph |
8000bph |
10000bph |
14000bph |
18000bph |
22000bph |
28000bph |
Complete mineral water bottling machine,pure water production line
Composition of the 60 heads machine:
The machine includes several sections listed bellows:
(1). Drive unit
(2). Locating bottle device
(3). Input bottle device
(4). Rinsing bottle device
(5). Rinsing-filling transferring bottle device
(6). Filling device
(7). Filling-capping transferring bottle device
(8). Capping device
(9). Unscrambling device
(10). Output bottle device
(11). Frame
(12). Electric control system
Complete mineral water bottling machine,pure water production line
