Automatic grape wine bottle filling machine
Detailed Product Description:
1.filling machine for automatic grape wine bottle filling machine
2.full automatic 3-in-1 monobloc automatic grape wine bottle filling machine
3.suitble bottle: plastic bottle and glass bottle
filling machine/filling machinery
(1) all parts of the filling machine touch with the material adopt high quality stainless still. Through the polishing treatment the surface become easy to clean. Sealed material is rubber or EPDM material.
(2) Using programmle controller as the central control,using pressure transmitter, electromagnetic chaos pneumatic servo measurement level to maintian the balance of filling pressure in order to ensure the stability of the liquid surface.
(3) Designed new filling valve for plastic bottle, return-air and filling tank liquid are separation to ensure the cleaning of filling materials.
(4) The automatic grape wine bottle filling machine adopts advanced magnetic clutch-type screw cover head, torque is adjustable. Screwing cap is safe and reliable.
Wine Bottle Filling Machine
Model(WCGF) |
12-12-4 |
18-18-6 |
24-24-8 |
32-32-8 |
40-40-10 |
50-50-12 |
60-60-15 |
80-80-20 |
Number of washing,filling,capping heads |
12-12-4 |
18-18-6 |
24-24-8 |
32-32-8 |
40-40-10 |
50-50-12 |
60-60-15 |
80-80-20 |
Suited bottle specification (mm) |
Φ=50-100 H=170 330-1500ML |
Φ50-Φ110 H=160-340 |
||||||
Production capacity(350ML)b/h |
2000-4000 |
4000-6000 |
8000-10000 |
10000-12500 |
12500-15000 |
16000-20000 |
20000-24000 |
26000-32000 |
Washing pressure(MPa) |
0.2-0.25 |
0.2-0.25 |
||||||
Filling pressure(MPa) |
0.15-0.35 |
0.15-0.35 |
0.15-0.35 |
0.2-0.4 |
0.2-0.4 |
0.2-0.4 |
0.2-0.4 |
0.2-0.4 |
Motor power |
1.5+0.55+0.12 |
2.2+0.55+0.18 |
3+0.55+0.18 |
5.5+0.55+0.18 |
7.5 |
11 |
15 |
19 |
Overall dimensions(L×W×H)mm |
2300×1600×2500 |
2600×1920×2550 |
3100×2200×2800 |
3850×3000×2850 |
4850×3800×2750 |
5750×3550×2750 |
6500×5500×2750 |
7680×6640×2650 |
Weight kg |
2800 |
3650 |
4800 |
6800 |
8650 |
10500 |
12800 |
|
Product show
