Compressed Air Dryer

Compressed Air Dryer thumbnail-1
Compressed Air Dryer photo-1
US$ 2,000 - 5,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Reciprocating, Compressed Air Dryer
Configuration:
Stationary
Contact Supplier Request Quote Chat Now
Zhangjiagang Mars Packing Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, Reciprocating, Compressed Air Dryer
Configuration Stationary
Power Source AC Power
Lubrication Style Oil-less
Place of Origin Jiangsu, China
Brand Name Mars
Model Number CAD-1
Voltage 380/3ph/50Hz
Dimension(L*W*H) 630mm x 450mm x 640mm
Weight 50Kg
Certification CE
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

 Compressed Air dryer





Perfect refrigerated system Energy Conservation Varied Specification

High(Norml) Inlet Temperature Air-Cooling Refrigerated Air Dryer



Technic Information:



Inlet temperature:  ≤80°C(45°C)                    Pressure drop: ≤0.03Mpa

Cooling methord:  Air-cooling                      Dew point: 2~10°C

Inlet pressure:  0.4~1.3 Mpa                          Refrigerant: R22



Technic Information:



              Model No. Item SAD-1 HTF     SAD-2 HTF SAD-3 HTF SAD-6 HTF SAD-8 HTF SAD-10 HTF SAD-13 HTF SAD-15 HTF

SAD-20

H(N)TF

 SAD-25 H(N)TF SAD-30 H(N)TF SAD-40 H(N)TF SAD-50 H(N)TF SAD-60 H(N)TF
Air Flow (Nm3/Min) 1.2 2.4 3.8 6.5 8.5 10.7 13.5 18 23 28 33 45 55 65
Power Supplier(V/Hz) 220/20 220/20 220/20 220/20 220/20 380/50 380/50 380/50 380/50 380/50 380/50 380/50 380/50 380/50
Motor Power(kw) 1/0.85 1/0.85 1.25/1.25 1.5/1.5 2.5/1.8 3/2.5 3/2.5 3.6/3 5.4/4.0 6.0/4.5 7.5/6.5 10.5/8.8 12/10.2 15/13
Fan Power (kw) 90 90 140 180 180 2*140 2*140 4(2)*180 4(2)*220 4(2)*250 6(3)*250 6(3)*250 6(3)*450 8(4)*180
Pipe Size (inch) ZG1 ZG1 ZG1.5 ZG1.5 ZG1.5 ZG2 ZG2 DN65 DN80 DN8 DN100 DN100 DN125 DN125
Weight(kgs) 50 80 105 150 160 240 260 310 400 450 780 820 900 1100
Dimension (mm) L 630 700 850 880 880 1180 1180 1360 1360 1650 1670 2000 2350 2550
W 450 450 500 550 550 670 670 710 710 750 750 950 1050 1100
H 640 830 920 1020 1020 1080 1080 1220 1220 1290 1575 1740 1910 1940





Product Features:



1.Advanced technology



2.Prefect refrigerated system configuration



3.Energy conservation



4.Gas liquid separated thoroughly



5. Good drainage system



6.Unique outer box and air exhaust design



7.Multi-control of circuitry to supply



8.Superior condenser



Product show

Compressed Air Dryer
