Tubular Pasteurized Sterilizer
- 100 Set / Sets per Month
- NINGBO OR SHANGHAI
- High Quality Hot Milk Juice Tubular Type Uht Sterilizer Pasteurization Equipment Machine
- Factory Dairy making machine/mini pasteurized milk & yogurt processing plant/long life UHT milk production line machinery
- 500l-1000 L/H Multi Tube Uht Sterilizer Tubular Type Pasteurizer Juice Sterilizer Machine
- Water Bath Vacuum Packaged Food Pasteurizer Machine/Tunnel Tomato Paste Pasteurization Machine
- Dairy Greek Yogurt Make Machine 1000L Milk Pasteurizer Pasteurizadora De Leche Milk Sterilizer Machine
- Factory Dairy making machine/mini pasteurized milk & yogurt processing plant/long life UHT milk production line machinery
Product Details
Condition: | New | Place of Origin: | Guangdong, China | Brand Name: | huihe |
Model Number: | huihe-110 | Processing Types: | Milk | Voltage: | 220V/380V |
Power(W): | 2.2KW | Weight: | made to order | Dimension(L*W*H): | Based |
Certification: | ISO | Warranty: | 1 Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
1. The host of automatic tube sterilizer of fresh fruit juice is tube type high temperature sterilizer. The machine has characteristics such as compact structure, effective sterilization, convenient operation, wide adaptation, low cost and so on. According to users’ needs, it can be supplied separately UHT sterilization system, including tube-type sterilizing machine, preheating tank, and insulation tank, the homogenizer interfaces can prevent formatting milk stone, with the pasteurization function. It can also available the entire unit, including UHT sterilizing system and flash degassing system.
2. The host of automatic tubular pasteurizer system is tube type high temperature sterilizer. The machine has characteristics such as compact structure, effective sterilization, convenient operation, wide adaptation, low cost and so on. According to users’ needs, it can be supplied separately UHT sterilization system, including tube-type sterilizing machine, preheating tank, and insulation tank, the homogenizer interfaces can prevent formatting milk stone, with the pasteurization function. It can also available the entire unit, including UHT sterilizing system and flash degassing system.
3. Design specification
Usage:sterilization of liquid product
Effect:commercial sterilization
Sterilization temperature: 135°C
4. Process parameter:
A Sterilized milk :5°C→65°Chomogeneity→95°C(30S)→140°C(4S)→25°C
B. Sterilized soya milk:65°Chomogeneity→135°C(15S)→28°C
C. Fresh juice:25°C→105°C(10S)→90°C→40°C backflow
5.Characteristics :
J Not easy coking, longer producing time
J Material is reliable, high operating pressure
J The product can bring grain, suitable for high viscosity material processing
J Easy to clean, low maintenance cost
J PLC control, with the man-machine interface, easy operation
J Import and export temperature easy to control
Offer tubular style sterilizer UHT/plate type UHT/ pipe-wind type UHT
Pipe complete set of sterilizing equipment is a disposal sterilizing equipment for
prolonging quality validity through sterilizing and cooling.According to different
material heating,sterilizing and different technological demand of keeping
temperature and cooling,carrying out the flow chart assemblydesign ,possess various
complete protective measurement,with high automation degree and accurate control.
Suitable soope:Diary production,Fruitjuice,Drink,Syrup,Suce Vinegar.
